无托槽隐形矫治下前牙压低过矫治的回归分析研究

doi:10.13591/j.cnki.kqyx.2024.05.002

摘要/Abstract

摘要：

目的通过分析下前牙压低的最终实现值与方案预设值之间的关系,探究一种过矫治计算方法以及相关影响因素。方法纳入20例采用隐适美隐形矫治器压低下前牙的患者。将ClinCheck方案中的相对压低值记为压低预设值,经数字化模型重叠技术测得压低实现值。评估实现值与预设值的差异和关系,分析压低量等因素对压低效率的影响。结果下前牙压低的平均效率约为62.2%,中切牙效率最高,尖牙最低。压低量、下切牙唇倾度和下尖牙区附件类型均影响压低效率。压低预设值与实现值之间差异显著,存在线性关系。下前牙压低过矫治量计算公式为Z=(W-0.110)/0.533-W(Z为过矫治量,W为期望压低量)。结论矫治方案中的下前牙预设压低量不能完全实现,对于设计下尖牙压低,或压低量大,或初始位下切牙舌倾的病例应设计更多过矫治。与优化附件相比,下尖牙设计垂直矩形附件更有利于提高压低效率。

关键词: 无托槽隐形矫治, 前牙压低, 效率, 线性回归, 过矫治

Abstract:

Objective To explore an overcorrection quantization method and related influencing factors through analyzing relationships between the achieved and preset intrusion values of mandibular anterior teeth with clear aligners. Methods Twenty patients receiving Invisalign were recruited. The relative intrusion values in the ClinCheck software were recorded as the preset intrusion. The achieved intrusion values were measured through the digital model superimposition. Statistical analysis was conducted to assess the differences and linear relationships between the preset and achieved intrusion values, and investigate the effect of related factors such as intrusion amounts on the intrusion efficiency. Results For the mandibular anterior teeth, the mean intrusion efficiency was 62.2%, with the highest in the central incisors and the lowest in the canines. The intrusion amounts, incisors labial inclinations, and canine attachment types affected the intrusion efficiency. The differences between the preset and achieved values were significant, and the linear relationship existed. The formula of the intrusion overcorrection for the mandibular anterior teeth is “Z=(W-0.110)/0.533-W”. Z represents the overcorrection and W represents the ideal intrusion. Conclusion The preset intrusion values in the treatment protocol could not be fully achieved. Moreover, correction should be designed in cases of mandibular canine intrusion, large amountsof intrusion, orlingually inclined incisors. Compared to the optimized attachments, the vertical rectangular attachments on the mandibular canines could improve the efficiency.

Key words: clear aligners, anterior teeth intrusion, efficiency, linear regression, overcorrection

中图分类号:

R783.5

黄钖钖, 王诗语, 刘浩, 杨丽, 王鹏来, 袁长永. 无托槽隐形矫治下前牙压低过矫治的回归分析研究[J]. 口腔医学, 2024, 44(5): 329-333.

HUANG Yangyang, WANG Shiyu, LIU Hao, YANG Li, WANG Penglai, YUAN Changyong. A regression analysis of the overcorrection for the mandibular anterior teeth in trusion with clear aligners[J]. Stomatology, 2024, 44(5): 329-333.

图/表 9

图1

图2

图3

图4

图5

表1

表2

压低实现值与预设值的相关与线性回归分析"

牙位	$r$	P₂	R²	F	P₃	过矫治量
下前牙	0.921	<0.01^**	0.849	661.178	<0.01^**	Z=(W-0.110)/0.533-W
下中切牙	0.930	<0.01^**	0.865	243.042	<0.01^**	Z=(W-0.108)/0.561-W
下侧切牙	0.909	<0.01^**	0.826	180.532	<0.01^**	Z=(W-0.165)/0.512-W
下尖牙	0.940	<0.01^**	0.884	290.148	<0.01^**	Z=(W-0.063)/0.525-W

表2

图6

表3

参考文献 23

[1]	Kravitz ND, Kusnoto B, BeGole E, et al. How well does Invisalignwork? A prospective clinical study evaluating the efficacy of tooth movement with Invisalign[J]. Am J Orthod Dentofacial Orthop, 2009, 135(1):27-35.
[2]	Haouili N, Kravitz ND, Vaid NR, et al. Has Invisalign improved? A prospective follow-up study on the efficacy of tooth movement with Invisalign[J]. Am J Orthod Dentofacial Orthop, 2020, 158(3):420-425.
[3]	Meade MJ, Weir T. Predicted and achieved overjet and overbite measurements with the Invisalign appliance: A retrospective study[J]. Angle Orthod, 2024, 94(1):3-9.
[4]	Kravitz ND, Hansa I, Vaid NR, et al. Does age influence deep overbite correction with Invisalign? A prospective study evaluating mandibular incisor intrusion in adolescents vs adults[J]. Angle Orthod, 2024, 94(2):145-150.
[5]	Al-Nadawi M, Kravitz ND, Hansa I, et al. Effect of clear aligner wear protocol on the efficacy of tooth movement[J]. Angle Orthod, 2021, 91(2):157-163. doi: 10.2319/071520-630.1 pmid: 33296455
[6]	Shahabuddin N, Kang J, Jeon HH. Predictability of the deep overbite correction using clear aligners[J]. Am J Orthod Dentofacial Orthop, 2023, 163(6):793-801.
[7]	胡炜. 试论无托槽隐形矫治的垂直向控制[J]. 中华口腔医学杂志, 2020, 55(8):526-530.
[8]	Lam J, Freer E, Miles P. Comparative assessment of treatment efficiency and patient experience between Dental Monitoring and conventional monitoring of clear aligner therapy: A single-center randomized controlled trial[J]. Am J Orthod Dentofacial Orthop, 2023, 163(4):456-464.
[9]	Al-Balaa M, Li HY, Mohamed AM, et al. Predicted and actual outcome of anterior intrusion with Invisalign assessed with cone-beam computed tomography[J]. Am J Orthod Dentofacial Orthop, 2021, 159(3):e275-e280.
[10]	Ren LH, Liu L, Wu ZQ, et al. The predictability of orthodontic tooth movements through clear aligner among first-premolar extraction patients: A multivariate analysis[J]. Prog Orthod, 2022, 23(1):52. doi: 10.1186/s40510-022-00447-y pmid: 36581703
[11]	Simon M, Keilig L, Schwarze J, et al. Treatment outcome and efficacy of an aligner technique: Regarding incisor torque, premolar derotation and molar distalization[J]. BMC Oral Health, 2014, 14: 68.
[12]	赵佳媛, 胡成思, 金玉, 等. 无托槽隐形矫治器伸长后牙效率的三维重叠分析[J]. 上海口腔医学, 2022, 31(5):556-560.
[13]	Tang ZX, Chen WC, Mei L, et al. Relative anchorage loss under reciprocal anchorage in mandibular premolar extraction cases treated with clear aligners[J]. Angle Orthod, 2023, 93(4):375-381. doi: 10.2319/102222-727.1 pmid: 37343197
[14]	Yan XY, Zhang XQ, Ren LH, et al. Effectiveness of clear aligners in achieving proclination and intrusion of incisors among Class Ⅱ division 2 patients: A multivariate analysis[J]. Prog Orthod, 2023, 24(1):12.
[15]	Blundell Dr HL, Dr TW, Dr BK, et al. Predictability of overbite control with the Invisalignappliance[J]. Am J Orthod Dentofacial Orthop, 2021, 160(5):725-731.
[16]	Bilello G, Fazio M, Amato E, et al. Accuracy evaluation of orthodontic movements with aligners: A prospective observational study[J]. Prog Orthod, 2022, 23(1):12. doi: 10.1186/s40510-022-00406-7 pmid: 35399128
[17]	Muro MP, Caracciolo ACA, Patel MP, et al. Effectiveness and predictability of treatment with clear orthodontic aligners: A scoping review[J]. Int Orthod, 2023, 21(2):100755.
[18]	Palone M, Pignotti A, Morin E, et al. Analysis of overcorrection to be included for planning clear aligner therapy: a retrospective study[J]. Angle Orthod, 2023, 93(1):11-18.
[19]	Rozzi M, Tiberti G, Mucedero M, et al. Leveling the curve of Spee: Comparison between continuous archwire treatment and Invisalign system: A retrospective study[J]. Am J Orthod Dentofacial Orthop, 2022, 162(5):645-655.
[20]	Li YX, Xiao SZ, Jin Y, et al. Stress and movement trend of lower incisors with different IMPA intruded by clear aligner: A three-dimensional finite element analysis[J]. Prog Orthod, 2023, 24(1):5. doi: 10.1186/s40510-023-00454-7 pmid: 36775824
[21]	Liu Y, Hu W. Force changes associated with different intrusion strategies for deep-bite correction by clear aligners[J]. Angle Orthod, 2018, 88(6):771-778. doi: 10.2319/121717-864.1 pmid: 30035613
[22]	康芙嘉, 吴聿淼, 刘心雨, 等. 不同前牙唇倾度及内收压低步距下隐形矫治器作用的比较: 三维有限元研究[J]. 口腔医学研究, 2023, 9(4):345-349.
[23]	胥鹏飞, 张闵, 范智博, 等. 无托槽隐形矫治中牙周炎患者下切牙压低的三维有限元研究[J]. 口腔医学研究, 2022, 38(8):757-761. doi: 10.13701/j.cnki.kqyxyj.2022.08.012

牙位	n	预设值/mm	实现值/mm	差值/mm	t	P₁	效率/%
下前牙	120	1.602±0.728	0.965±0.422	0.637±0.377	18.494	<0.01^**	62.2±11.6
下中切牙	40	1.578±0.726	0.994±0.438	0.584±0.357	10.343	<0.01^**	64.9±11.3
下侧切牙	40	1.650±0.731	1.010±0.412	0.641±0.396	10.229	<0.01^**	64.0±12.2
下尖牙	40	1.578±0.743	0.891±0.415	0.687±0.380	11.423	<0.01^**	57.7±10.2

指标	n	β	SE	95%CI	P
压低量		-0.059	0.013	(-0.086,-0.032)	<0.010^**
下颌平面角		0.002	0.003	(-0.003,0.007)	0.480
下切牙唇倾度		0.005	0.002	(0.001,0.009)	0.019^*
尖牙区附件类型
优化旋转	13	Ref.
优化控根	13	-0.007	0.023	(-0.054,0.039)	0.761
垂直矩形	14	0.049	0.023	(0.004,0.094)	0.034^*
