3种根管封闭剂根尖封闭性能的Micro-CT研究

doi:10.13591/j.cnki.kqyx.2024.06.008

摘要/Abstract

摘要：

目的使用微计算机断层扫描技术(micro-computed tomography,Micro-CT)分析比较3种根管封闭剂(C-Root SP、iRoot SP和AH-Plus Jet)在单尖法根管充填中对根管充填封闭性能。方法收集90颗符合纳入标准的下颌单根管离体前磨牙,使用ProTaper Next预备至X3,然后随机分为3个实验组C-Root SP组(A组)、iRoot SP组(B组)、AH-Plus Jet组(C组),均采用单尖法进行根管充填,并进行1周的口腔环境模拟,最后用Micro-CT测量根管内气泡体积及其所占比例来评价比较3种根管封闭剂的封闭性能。结果 A、B、C组在根管的不同部位(下1/3段、中1/3段、上1/3段)均存在可识别的气泡。在下1/3段中,A组的气泡体积(0.01±0.01)mm³与C组(0.12±0.08)mm³相比存在统计学差异(P<0.05),与B组(0.02±0.01)mm³相比则没有统计学差异;在中1/3段与上1/3段,组间无统计学差异。在根管全长范围内,A组的气泡总体积最小(0.15±0.03)mm³,B、C两组分别为(0.22±0.11)mm³、(0.34±0.28)mm³,A组与B组相似,均优于C组。结论 C-Root SP的根尖封闭性能与iRoot SP接近,且优于AH-Plus Jet,C-Root SP可以作为良好的根管封闭剂选择。

关键词: C-Root SP, iRoot SP, AH-Plus Jet, Micro-CT, 根管封闭剂

Abstract:

Objective To evaluate and compare the impact of three root canal sealers (C-Root SP, iRoot SP, and AH-Plus Jet) on the sealing performance in single-cone root canal filling using micro-computed tomography (Micro-CT). Methods Ninety mandibular single-rooted extracted teeth meeting inclusion criteria were collected, prepared with Protaper Next up to X3, and randomly assigned to three experimental groups which were C-Root SP group (Group A), iRoot SP group (Group B), and AH-Plus Jet group (Group C). Subsequently, all three groups underwent single-cone root canal filling, followed by one week of oral environment simulation. The sealing performance of the three root canal sealers was evaluated by measuring the proportion of the root canal volume and its rate using Micro-CT. Results In different segments of the roots (upper 1/3, middle, and lower), identifiable bubbles were observed in the Group A, Group B and Group C, with volumes of (0.15±0.03)mm³, (0.22±0.11)mm³, and (0.34±0.28) mm³, respectively. Overall, Group A exhibited the smallest bubble volume (0.15±0.03) mm³. Group A and B were similar, they were superior to group C. (P<0.05) Nevertheless, in the apical 1/3 segment (0-3 mm), a significant statistical difference was observed between the bubble volumes of Group A (0.01±0.01)mm³ and Group C (0.12±0.08)mm³ (P<0.05), while no significant difference was observed compared to Group B. Conclusion The apical sealing performance of C-Root SP is similar to iRoot SP and superior to AH-Plus Jet. C-Root SP can be considered as a favorable choice for root canal sealer.

Key words: C-Root SP, iRoot SP, AH-Plus Jet, Micro-CT, root canal sealer

中图分类号:

R781.05

赵麒桐, 王艳茹, 张敏, 张琪, 李谨, 雷港. 3种根管封闭剂根尖封闭性能的Micro-CT研究[J]. 口腔医学, 2024, 44(6): 443-447.

ZHAO Qitong, WANG Yanru, ZHANG Min, ZHANG Qi, LI Jin, LEI Gang. Sealing performance of three root canal sealers in vitro: A Micro-CT study[J]. Stomatology, 2024, 44(6): 443-447.

图/表 3

参考文献 28

[1]	许婉倩, 王梓, 薛明. 生物陶瓷类封闭剂的封闭性能[J]. 中国实用口腔科杂志, 2023, 16(5):522-525.
[2]	徐章凤, 张昊, 周永庆. 单尖法和热牙胶法根管充填根尖封闭性能的比较研究[J]. 口腔医学, 2023, 43(2):114-117.
[3]	凌均棨, 林正梅, 房俊艳, 等. 树脂牙本质粘接在根管充填治疗中的应用和展望[J]. 华西口腔医学杂志, 2011, 29(1):1-4.
[4]	雷港, 魏昕, 闫明, 等. MTA和iRoot BP plus治疗根尖孔未闭合恒牙根尖周炎的临床疗效分析[J]. 口腔医学, 2023, 43(2):118-124.
[5]	Sah S, Mangat P, Kumar A, et al. Stereomicroscopic evaluation of sealing ability of four different root canal sealers: An in-vitro study[J]. BMC Oral Health, 2024, 24(1):258.
[6]	Celikten B, Uzuntas CF, Orhan AI, et al. Evaluation of root canal sealer filling quality using a single-cone technique in oval shaped canals: An in vitro Micro-CT study[J]. Scanning, 2016, 38(2):133-140. doi: 10.1002/sca.21249 pmid: 26228657
[7]	Huang Y, Orhan K, Celikten B, et al. Evaluation of the sealing ability of different root canal sealers: A combined SEM and micro-CT study[J]. J Appl Oral Sci, 2018, 26: e20160584.
[8]	Giovarruscio M, Sauro S, Makeeva I, et al. Strategies to reduce the risk of reinfection and cross-contamination in endodontics[J]. Clin Dent Rev, 2019, 3(1):8.
[9]	Li J, Chen LC, Zeng CM, et al. Clinical outcome of bioceramic sealer iRoot SP extrusion in root canal treatment: A retrospective analysis[J]. Head Face Med, 2022, 18(1):28. doi: 10.1186/s13005-022-00332-3 pmid: 36045447
[10]	胡诚, 孙建勋, 陈新梅. 新型常温流动牙胶GuttaFlow2的研究进展[J]. 牙体牙髓牙周病学杂志, 2017, 27(9):541-544, 505.
[11]	梁宇红, 岳林. 根管治疗技术之根管充填和冠方封闭[J]. 中华口腔医学杂志, 2019, 54(12):859-863.
[12]	李秀丽, 杨玥, 侯本祥, 等. 4种根管封闭剂根尖封闭效果的体外实验研究[J]. 北京口腔医学, 2014, 22(4):200-203.
[13]	Zare S, Shen I, Zhu Q, et al. Micro-computed tomographic evaluation of single-cone obturation with three sealers[J]. Restor Dent Endod, 2021, 46(2):e25. doi: 10.5395/rde.2021.46.e25 pmid: 34123761
[14]	Komabayashi T, Colmenar D, Cvach N, et al. Comprehensive review of current endodontic sealers[J]. Dent Mater J, 2020, 39(5):703-720.
[15]	Liu H, Lai WWM, Hieawy A, et al. Micro-computed tomographic evaluation of the quality of root canal fillings in mandibular molars after obturation for 54 months[J]. J Endod, 2021, 47(11):1783-1789. doi: 10.1016/j.joen.2021.08.015 pmid: 34492231
[16]	Chybowski EA, Glickman GN, Patel Y, et al. Clinical outcome of non-surgical root canal treatment using a single-cone technique with endosequence bioceramic sealer: A retrospective analysis[J]. J Endod, 2018, 44(6):941-945. doi: S0099-2399(18)30132-8 pmid: 29606401
[17]	莫清波. 单尖法根管充填临床对比研究[J]. 口腔医学, 2016, 36(7):632-634, 652.
[18]	吕翱, 林晓新, 郭晓莉, 等. 3种根管封闭剂的根尖封闭性能体外比较研究[J]. 中国实用口腔科杂志, 2022, 15(3):300-303.
[19]	于敏, 贺洪远, 郑智明, 等. iRootSP糊剂热牙胶垂直加压与AH-Plus糊剂热牙胶垂直加压、iRootSP冷侧压在C形根管充填中的效果比较[J]. 新疆医科大学学报, 2023, 46(5):663-667.
[20]	Kandemir Demirci G, Çöven FO, Güneri P, et al. The solubility, pH value, chemical structure, radiopacity, and cytotoxicity of four different root canal sealers: An in vitro study[J]. Clin Oral Investig, 2023, 27(9):5413-5425.
[21]	吴於芝, 何敏, 刘燕. iRoot SP用于根管三维充填的抗折性研究[J]. 牙体牙髓牙周病学杂志, 2017, 27(12):702-705.
[22]	吴秉民. 预混合的硅酸锶基生物学水凝性粘固粉糊剂组合物及其制备方法和应用: CN108721693B[P]. 2021-03-12.
[23]	Saidak Z, Marie PJ. Strontium signaling: Molecular mechanisms and therapeutic implications in osteoporosis[J]. Pharmacol Ther, 2012, 136(2):216-226.
[24]	Xing M, Wang XY, Wang ED, et al. Bone tissue engineering strategy based on the synergistic effects of silicon and strontium ions[J]. Acta Biomater, 2018, 72: 381-395. doi: S1742-7061(18)30182-X pmid: 29627679
[25]	Lin KL, Xia LG, Li HY, et al. Enhanced osteoporotic bone regeneration by strontium-substituted calcium silicate bioactive ceramics[J]. Biomaterials, 2013, 34(38):10028-10042. doi: 10.1016/j.biomaterials.2013.09.056 pmid: 24095251
[26]	Jing Y, Gong T, Duan CG, et al. In vitro cytocompatibility and osteogenic potential of calcium silicate-based dental cements in a root canal-filling model[J]. J Int Med Res, 2020, 48(4):030006051989480.
[27]	Alves SM, Abreu SC, Lemos JC, et al. Anti-inflammatory and anti-nociceptive effects of strontium ranelate on the zymosan-induced temporomandibular joint inflammatory hypernociception in rats depend on TNF-α inhibition[J]. Pharmacol Rep, 2017, 69(4):764-772. doi: S1734-1140(17)30197-4 pmid: 28587937
[28]	雷港, 卞敏霞, 李娜, 等. C-Root SP和iRoot SP生物陶瓷封闭剂根管充填超填率及术后疼痛的对比研究[J]. 口腔生物医学, 2023, 14(1):29-34, 45.

分组	根管分段	根管封闭剂	气泡	牙胶
A组	0~3 mm	0.07±0.02	0.01±0.01	0.72±0.05
	3~6 mm	0.09±0.03	0.05±0.01	0.94±0.04
	6~9 mm	0.11±0.06	0.09±0.01	1.26±0.20
	合计	0.27±0.11	0.15±0.03	2.92±0.34
B组	0~3 mm	0.05±0.05	0.02±0.01	0.74±0.07
	3~6 mm	0.08±0.03	0.07±0.04	0.90±0.22
	6~9 mm	0.12±0.09	0.13±0.15	1.30±0.28
	合计	0.25±0.18	0.22±0.11	2.94±0.47
C组	0~3 mm	0.14±0.10	0.12±0.10^*	0.69±0.08
	3~6 mm	0.12±0.11	0.10±0.08	0.85±0.08
	6~9 mm	0.22±0.18	0.12±0.13	1.18±0.09
	合计	0.48±0.39	0.34±0.28	2.72±0.24
