无托槽隐形矫治拔牙病例的后牙不同轴倾度对牙齿三维力学影响

doi:10.13591/j.cnki.kqyx.2023.02.002

Abstract

Abstract:

Objective To investigate the three-dimensional forces in real-time at different tips of the posteriors created by clear aligners on maxillary teeth during en-masse retraction of anteriors after 2 first premolars extraction treatment. Methods Four groups of maxillary models with different tips of posteriors(T1-upright of posteriors, T2-posteriors with distal inclination of 5°, T3-posteriors with mesial inclination of 5°, T4-posteriors with mesial inclination of 10°) undergoing 0.25 mm en-masse retraction treatment using clear aligners were simulated on a multi-axis force/torque transducer measurement system. When each clear aligner was inserted, a computer connected to the transducer collected and recorded the three-dimensional force of every tooth in real-time. Each group included 12 aligners. Results Incisors received smaller lingual and extrusive forces; canines received greater distal forces; smaller mesial forces were observed on the posteriors, and molars received greater buccal and extrusive forces in T2,compared with T1,which showed statistically significant differences(P<0.05). Incisors received smaller lingual and extrusive forces; canines received greater distal forces; greater mesial forces were observed on the posteriors, and molars received greater buccal and extrusive forces in T3 and T4,compared with T1,which showed statistically significant differences(P<0.05). Conclusion Posteriors with distal inclination contributed to the torque of the anterior and anchorage of posteriors. In group T2 posterior teeth experienced larger buccal forces and extrusive forces than in group T1. When the posteriors crown inclined mesially, the anterior teeth were more prone to lingual tip and caused overbite. The more mesially inclined the posterior teeth were, the more serious overbite was, and the posterior teeth were more prone to anchorage loss.

Key words: orthodontics, clear aligner, extraction, tips of posteriors, three-dimensional forces

CLC Number:

R783.5

FAN Yongjie,KOU Yating. Effect of different tips of posteriors in extraction treatment on three-dimensional forces of teeth with clear aligners[J]. Stomatology, 2023, 43(2): 104-109.

Figures/Tables 5

Tab.1

Fig.1

Fig.2

Tab.2

Force distribution within aligners and comparisons of the forces in four groups N"

牙位	力的方向	T1	T2	T3	T4	P
17	X	-0.48±0.41	-0.88±0.36	-0.64±0.07	-0.95±0.26	0.001
	Y	0.36±0.04	0.16±0.14	0.84±0.27	0.25±0.33	0.016
	Z	0.38±0.28	0.75±0.40	0.60±0.25	0.36±0.37	0.311
16	X	0.09±0.35	-0.15±0.41	-0.25±0.52	-0.28±0.06	0.002
	Y	0.46±0.60	0.28±0.29	0.57±0.72	0.39±0.23	0.000
	Z	0.32±0.07	0.46±0.68	0.58±0.16	0.67±0.17	0.000
15	X	-0.12±0.49	-0.26±0.59	-0.16±0.45	-0.39±0.48	0.737
	Y	0.38±0.30	0.26±0.29	0.74±0.18	0.29±0.61	0.004
	Z	-0.26±0.34	-0.30±0.20	0.20±0.03	-0.67±0.13	0.000
13	X	0.24±0.22	-0.16±0.05	0.27±0.05	0.31±0.36	0.038
	Y	-2.94±0.53	-3.52±0.27	-3.74±0.73	-3.93±0.65	0.006
	Z	-0.28±0.02	-0.19±0.08	-0.34±0.47	-0.32±0.30	0.015
12	X	0.77±0.72	0.43±0.48	1.87±0.58	2.43±0.59	0.201
	Y	-0.05±0.29	-0.23±0.16	0.02±0.43	-0.17±0.20	0.000
	Z	0.22±0.27	0.15±0.34	0.43±0.17	0.58±0.41	0.000
11	X	0.30±0.38	0.77±0.29	1.23±0.37	2.35±0.65	0.077
	Y	0.09±0.10	-0.46±0.61	-0.30±0.06	0.27±0.09	0.000
	Z	0.43±0.17	0.38±0.07	0.19±0.26	0.42±0.13	0.000
21	X	1.17±0.47	0.89±0.35	1.79±0.32	1.74±0.35	0.276
	Y	0.37±0.55	-0.16±0.19	0.30±0.08	0.31±0.11	0.006
	Z	0.27±0.36	0.14±0.05	0.37±0.06	0.39±0.09	0.000
22	X	1.09±0.11	0.66±1.10	1.65±0.65	2.76±0.22	0.000
	Y	0.36±0.17	-0.09±0.42	0.54±0.13	0.22±0.35	0.009
	Z	0.47±0.32	0.05±0.14	0.71±0.16	0.57±0.15	0.084
23	X	-0.12±0.03	0.24±0.48	0.32±0.59	0.27±0.13	0.000
	Y	3.57±0.69	4.09±0.60	3.78±0.35	4.14±0.18	0.001
	Z	-0.33±0.21	0.05±0.21	-0.29±0.21	-0.58±0.33	0.086
25	X	-0.44±0.45	-0.53±0.17	-0.65±0.20	-0.49±0.14	0.012
	Y	-0.40±0.08	-0.35±0.32	-0.66±0.44	-0.27±0.31	0.039
	Z	0.13±0.16	-0.38±0.56	-0.54±0.20	-0.74±0.37	0.018
26	X	-0.31±0.22	-0.67±0.40	-0.47±0.16	-0.58±0.24	0.003
	Y	-0.54±0.16	-0.15±0.51	-0.74±0.02	-0.49±0.29	0.000
	Z	0.29±0.19	0.59±0.11	0.47±0.34	0.39±0.46	0.000
27	X	-0.26±0.30	-0.14±0.17	-0.34±0.19	-0.75±0.68	0.000
	Y	-0.57±0.35	-0.32±0.48	-0.86±0.17	-0.51±0.17	0.002
	Z	0.56±0.46	0.86±0.41	0.71±0.13	0.49±0.06	0.000

Tab.2

Fig.3

References 22

[1]	AlSeraidi M, Hansa I, Dhaval F, et al. The effect of vestibular, lingual, and aligner appliances on the quality of life of adult patients during the initial stages of orthodontic treatment[J]. Prog Orthod, 2021, 22(1):3. doi: 10.1186/s40510-020-00346-0 pmid: 33458787
[2]	Sharma R, Drummond R, Wiltshire W, et al. Quality of life in an adolescent orthodontic population[J]. Angle Orthod, 2021, 91(6):718-724. doi: 10.2319/062820-592.1 pmid: 34260709
[3]	Gao MY, Yan XY, Zhao R, et al. Comparison of pain perception, anxiety, and impacts on oral health-related quality of life between patients receiving clear aligners and fixed appliances during the initial stage of orthodontic treatment[J]. Eur J Orthod, 2021, 43(3):353-359. doi: 10.1093/ejo/cjaa037
[4]	Zhang B, Huang XQ, Huo SB, et al. Effect of clear aligners on oral health-related quality of life: A systematic review[J]. OrthodCraniofac Res, 2020, 23(4):363-370.
[5]	Zhu Y, Hu W, Li S. Force changes associated with differential activation of en-masse retraction and/or intrusion with clear aligners[J]. Korean J Orthod, 2021, 51(1):32-42. doi: 10.4041/kjod.2021.51.1.32 pmid: 33446619
[6]	Mehta S, Patel D, Yadav S. Staging orthodontic aligners for complex orthodontic tooth movement[J]. Turk J Orthod, 2021, 34(3):202-206. doi: 10.5152/TurkJOrthod.
[7]	Feng XX, Jiang YR, Zhu YF, et al. Comparison between the designed and achieved mesiodistal angulation of maxillary canines and posterior teeth and influencing factors: First premolar extraction treatment with clear aligners[J]. Am J Orthod Dentofacial Orthop, 2022, 162(2):e63-e70. doi: 10.1016/j.ajodo.2022.05.006
[8]	Kaur H, Truong J, Heo G, et al. An in vitro evaluation of orthodontic aligner biomechanics around the maxillary arch[J]. Am J Orthod Dentofacial Orthop, 2021, 160(3):401-409. doi: 10.1016/j.ajodo.2021.04.005
[9]	Jiang T, Wu RY, Wang JK, et al. Clear aligners for maxillary anterior en masse retraction: A 3D finite element study[J]. Sci Rep, 2020, 10(1):10156. doi: 10.1038/s41598-020-67273-2 pmid: 32576935
[10]	Gu JF, Tang JS, Skulski B, et al. Evaluation of Invisalign treatment effectiveness and efficiency compared with conventional fixed appliances using the Peer Assessment Rating index[J]. Am J Orthod Dentofacial Orthop, 2017, 151(2):259-266. doi: 10.1016/j.ajodo.2016.06.041
[11]	Liu Y, Hu W. Force changes associated with different intrusion strategies for deep-bite correction by clear aligners[J]. Angle Orthod, 2018, 88(6):771-778. doi: 10.2319/121717-864.1 pmid: 30035613
[12]	Badawi HM, Toogood RW, Carey JPR, et al. Three-dimensional orthodontic force measurements[J]. Am J Orthod Dentofacial Orthop, 2009, 136(4):518-528. doi: 10.1016/j.ajodo.2009.02.025
[13]	Major PW, Toogood RW, Badawi HM, et al. Effect of wire size on maxillary arch force/couple systems for a simulated high canine malocclusion[J]. J Orthod, 2014, 41(4):285-291. doi: 10.1179/1465313314Y.0000000099 pmid: 24852959
[14]	Andrews LF. The six keys to normal occlusion[J]. Am J Orthod, 1972, 62(3):296-309. doi: 10.1016/s0002-9416(72)90268-0 pmid: 4505873
[15]	Vaden JL. The tweed-Merrifield philosophy[J]. Semin Orthod, 1996, 2(4):237-240. pmid: 9161294
[16]	冯婷婷, 张晓芸, 苏红, 等. 生理性支抗Spee氏弓矫正系统对上前牙转矩控制的初步研究[J]. 中华口腔正畸学杂志, 2017, 24(3):121-127.
[17]	Bowman SJ, Celenza F, Sparaga J, et al. Creative adjuncts for clear aligners, part 2: Intrusion, rotation, and extrusion[J]. J Clin Orthod, 2015, 49(3):162-172.
[18]	安世英, 张继武, 马俐丽, 等. 无托槽隐形矫治技术内收上前牙的三维有限元分析[J]. 临床口腔医学杂志, 2020, 36(10):583-586.
[19]	马晓晴, 项飞, 樊明月, 等. 微种植钉辅助无托槽隐形矫治器控制“过山车”效应的疗效分析[J]. 上海口腔医学, 2022, 31(2):193-197.
[20]	封颖丽, 任亚男, 普盼君, 等. 无托槽隐形矫治中未设计移动上颌磨牙实际三维方向位移变化的临床研究[J]. 中华口腔正畸学杂志, 2020, 27(2):67-72.
[21]	Dai FF, Xu TM, Shu G. Comparison of achieved and predicted tooth movement of maxillary first molars and central incisors: First premolar extraction treatment with Invisalign[J]. Angle Orthod, 2019, 89(5):679-687. doi: 10.2319/090418-646.1
[22]	Dai FF, Xu TM, Shu G. Comparison of achieved and predicted crown movement in adults after 4 first premolar extraction treatment with Invisalign[J]. Am J Orthod Dentofacial Orthop, 2021, 160(6):805-813. doi: 10.1016/j.ajodo.2020.06.041
