快速生长期骨性安氏Ⅱ类下颌后缩患者使用无托槽隐形矫治器前导下颌的临床效果分析

doi:10.13591/j.cnki.kqyx.2023.03.010

Abstract

Abstract:

Objective To evaluate the effects of non-bracket invisible appliance mandibular advance(MA) on skeletal Class Ⅱ growing patients with mandibular retrusion. Methods Nineteen skeletal Class Ⅱ growing patients with mandibular retrusion who were treated in the department of stomatology of Changshu traditional Chinese medicine hospital from January 2018 to May 2021 were selected. They had an average age of (12.32±1.51) years old. The treatment group consisted of 10 children who were treated with MA. The control group consisted of 9 children who refused to treat their malocclusion. Cephalometrics of all patients were taken before and after the observation or treatment. The cephalometric data of two groups were analyzed. Results Compared with the control group, in the treatment gruop SNB angle, L1-NB angle, L1-NB distance, L6-MP distance, Z angle increased significantly (P<0.05);Co-Go distance, Co-Gn distance, SL increased more greatly than the control group; ANB angle, U1-SN angle, U1-NA angle, U1-NA distance, L1-MP distance, FCA angle decreased significantly (P<0.05); SE did not change significantly in the treatment group, but increased significantly in the control group (P<0.05). Conclusion MA can promote mandibular growth and improve lateral profile. The angle of the lower teeth and the angle of the mandible plane can be controlled by MA appliance.

Key words: mandibular retrusion, mandibular advancement, skeletal Class Ⅱ malocclusion, mandibular advance

CLC Number:

R783.5

CAO Weiqing, LIN Tangyi, LYU Dong. Research on clinical effects of non-bracket invisible appliance on the mandibular advancement treatment of skeletal Class Ⅱ growing patients with mandibular retrusion[J]. Stomatology, 2023, 43(3): 242-247.

Figures/Tables 4

Tab.1

Cephalometric analysis of two groups before and after treatment x ˉ±s"

测量指标	治疗组				对照组				两组差值对比
测量指标	术前	术后	差值	P	前	后	差值	P	P
SNA/(°)	80.60±2.95	80.68±3.03	0.08±0.74	0.74	80.00±2.49	80.12±2.55	0.12±0.46	0.39	0.89
SNB/(°)	74.58±2.97	76.88±2.58	2.30±0.99	0.00	74.07±2.60	74.30±2.62	0.23±0.71	0.29	0.00
ANB/(°)	6.13±1.24	3.80±0.79	-2.12±0.90	0.00	5.93±1.25	5.75±1.11	-0.18±0.87	0.48	0.00
SN-MP/(°)	32.06±5.12	31.76±5.03	-0.31±0.78	0.27	32.47±3.26	32.74±3.09	0.28±0.94	0.53	0.20
U1-SN/(°)	106.69±7.01	103.87±5.86	-2.82±1.92	0.00	108.50±6.13	108.39+6.11	-0.26+0.87	0.32	0.00
U1-NA/(°)	25.40±6.69	22.75±6.12	-2.65±2.10	0.00	27.92±6.10	28.18±5.76	0.26±1.15	0.45	0.00
U1-NA距/mm	6.08±1.58	4.81±1.70	-1.27±1.19	0.01	6.31±2.62	6.23±2.68	-0.08±0.33	0.44	0.00
U1-PP距/mm	27.53+1.46	27.66+1.53	0.13+0.53	0.48	27.17±2.58	26.95±2.33	-0.22±0.48	0.13	0.12
U6-PP距/mm	19.49±1.78	19.77±1.41	0.28±0.61	0.21	19.87±1.57	20.06±1.76	0.18±0.67	0.36	0.75
L1-NB/(°)	25.12±7.16	28.21±7.27	3.09±2.28	0.00	23.89±3.92	24.28±3.99	0.39±0.79	0.12	0.00
L1-NB距/mm	5.02±1.15	6.59±1.57	1.57±1.16	0.00	5.80±1.27	5.94±1.02	0.14±0.73	0.53	0.00
L1-MP/(°)	98.59±5.79	99.47±6.20	0.88±1.84	0.19	97.39±4.67	97.41±4.52	-0.02±0.67	0.93	0.15
L1-MP距/mm	37.00±2.35	36.31±2.06	-0.69±0.56	0.00	37.25±3.35	37.46±3.34	0.20±0.67	0.31	0.00
L6-MP距/mm	29.31±1.20	30.15±1.49	0.85±0.45	0.00	29.58±1.77	29.80±1.70	0.22±0.46	0.12	0.00
Co-Gn/mm	102.71±6.62	108.23±7.31	5.52±1.68	0.00	101.08±4.66	103.60±4.57	2.52±0.56	0.00	0.00
Co-Go/mm	49.84±3.85	53.01±3.73	3.08±0.65	0.00	50.15±3.78	51.86±3.66	1.71±0.54	0.00	0.00
Go-Gn/mm	68.02±2.78	70.95±2.03	2.93±0.91	0.00	66.46±2.65	68.98±2.56	2.51±0.69	0.00	0.15
SL/mm	40.30±5.08	43.01±5.50	2.71±0.65	0.00	39.40±3.84	41.10±3.94	1.70±0.66	0.00	0.00
SE/mm	19.63±1.91	19.92±1.69	0.29±0.47	0.10	19.03±1.81	19.87±1.81	0.85±0.54	0.00	0.03
FCA/(°)	16.06±3.07	9.57±3.07	-6.49±1.64	0.00	15.99±3.48	16.11±3.38	0.12±0.93	0.44	0.00
Z角/(°)	60.22±8.24	64.67±8.23	4.78±2.85	0.00	62.01±7.32	62.39±7.41	0.38±1.00	0.21	0.00

Tab.1

Fig.1

Fig.2

Fig.3

References 31

[1]	傅民魁. 口腔正畸专科教程[M]. 北京: 人民卫生出版社, 2007.
[2]	林久祥. 口腔正畸学[M]. 北京: 人民卫生出版社, 2011:173.
[3]	胡丽, 林久祥, 陈莉莉. 基于颈椎骨龄定量分期法的安氏Ⅱ类Ⅰ分类错牙合畸形患者最佳矫形时机的探讨[J]. 临床口腔医学杂志, 2013, 29(3):131-134.
[4]	Ravera S, Castroflorio T, Galati F, et al. Short term dentoskeletal effects of mandibular advancement clear aligners in Class Ⅱ growing patients. A prospective controlled study according to STROBE Guidelines[J]. Eur J Paediatr Dent, 2021, 22(2):119-124. doi: 10.23804/ejpd.2021.22.02.6 pmid: 34238001
[5]	苑迎娇, 陈亮, 胡通. GALL线评价Twin-Block治疗安氏Ⅱ类1分类的侧貌变化[J]. 实用口腔医学杂志, 2021, 37(6):845-848.
[6]	陈菁菁, 齐景, 袁洁莹, 等. Twin-block与MRC矫治生长高峰期伴口呼吸的骨性Ⅱ类疗效分析[J]. 临床口腔医学杂志, 2021, 37(2):98-102.
[7]	陈菁菁, 赵虎. Twin-block矫治生长高峰期伴口呼吸的骨性Ⅱ类疗效分析[J]. 医学研究与教育, 2021, 38(3):12-17.
[8]	李立国, 袁东辉, 左艳萍, 等. Twin-block与Headgear-activator矫治骨性Ⅱ类错牙合临床疗效对比研究[J]. 临床口腔医学杂志, 2012, 28(9):556-558.
[9]	李娜君, 赵春洋, 吴可, 等. Twin-block矫治器矫治安氏Ⅱ-1错牙合畸形的机制研究[J]. 口腔医学, 2019, 39(12):1082-1084,1112.
[10]	纪俐彣, 赵彦惠, 陈蕾, 等. MRC肌功能训练器和Twin-block矫治器治疗早期骨性Ⅱ类错牙合畸形患者的疗效[J]. 同济大学学报(医学版), 2020, 41(1):84-89.
[11]	陈延梅. Twin-Block和Activator功能矫治器矫治安氏Ⅱ-1类错牙合的比较研究[D]. 青岛: 青岛大学, 2018.
[12]	袁阳阳. SUS-2在安氏Ⅱ类错牙合治疗中作用机制的研究[D]. 大连: 大连医科大学, 2019.
[13]	黄朝阳, 肖俐娟, 赵玲. 改良肌激动器矫治生长发育期安氏Ⅱ类1分类畸形21例临床分析[J]. 广西医科大学学报, 2021, 38(7):1448-1452.
[14]	Xie L, Wang P, Wu JH. Soft and hard tissue changes following treatment of Class Ⅱ division 1 malocclusion with twin-block and myofunctional appliance:A pilot study[J]. Chin J Plast Reconstr Surg, 2020, 2(4):217-227.
[15]	吕冬, 顾鑫宇, 李琥, 等. 头帽Twin-block矫治器对骨性Ⅱ类错牙合患者软硬组织改变的影响[J]. 南京医科大学学报(自然科学版), 2015, 35(4):542-546.
[16]	杨琪琦, 陈雅莉, 周源, 等. 隐形MA与双板矫治器治疗早期骨性Ⅱ类下颌后缩错牙合的临床疗效[J]. 昆明医科大学学报, 2021, 42(3):29-34.
[17]	李阳. 无托槽隐形矫治器和Forsus矫治器治疗青少年下颌后缩患者的疗效对比[D]. 合肥: 安徽医科大学, 2021.
[18]	Caruso S, Nota A, Caruso S, et al. Mandibular advancement with clear aligners in the treatment of skeletal Class Ⅱ. A retrospective controlled study[J]. Eur J Paediatr Dent, 2021, 22(1):26-30. doi: 10.23804/ejpd.2021.22.01.05 pmid: 33719479
[19]	史香文. 成人骨性Ⅱ类深覆牙合患者正畸治疗前后颞下颌关节形态学改变的CBCT研究[D]. 大连: 大连医科大学, 2019.
[20]	李建霞, 邓锋, 宋锦璘, 等. 青少年下颌后缩型安氏Ⅱ-1类错牙合的髁突运动轨迹研究[J]. 第三军医大学学报, 2007, 29(14):1432-1435.
[21]	刘俊玲, 李洪发, 费丽思, 等. 恒牙期安氏Ⅱ-1颞下颌关节骨性结构的锥形束CT研究[J]. 口腔医学研究, 2013, 29(5):453-456.
[22]	贾文敏, 仇敏, 惠光艳, 等. Twin-block矫治器前导下颌对髁突位置的影响:定量测量分析[J]. 中国组织工程研究与临床康复, 2009, 13(52):10302-10304.
[23]	Arat ZM, Gökalp H, Erdem D, et al. Changes in the TMJ disc-condyle-Fossa relationship following functional treatment of skeletal Class Ⅱ Division 1 malocclusion:A magnetic resonance imaging study[J]. Am J Orthod Dentofacial Orthop, 2001, 119(3):316-319. doi: 10.1067/mod.2001.110245
[24]	Jiang YY, Sun L, Wang H, et al. Three-dimensional cone beam computed tomography analysis of temporomandibular joint response to the Twin-block functional appliance[J]. Korean J Orthod, 2020, 50(2):86-97. doi: 10.4041/kjod.2020.50.2.86
[25]	Croft RS, Buschang PH, English JD, et al. A cephalometric and tomographic evaluation of Herbst treatment in the mixed dentition[J]. Am J Orthod Dentofacial Orthop, 1999, 116(4):435-443. doi: 10.1016/S0889-5406(99)70230-1
[26]	刘丽, 段银钟, 赵文峰. Forsus矫治器对下颌后缩患者牙颌面及其髁状突综合效应的应用研究[J]. 口腔医学, 2014, 34(5):360-364.
[27]	陈维维, 伍军, 桑婷, 等. Herbst双期拔牙矫治对颞下颌关节位置影响的CBCT研究[J]. 实用口腔医学杂志, 2017, 33(4):496-499.
[28]	周传丽, 白玉兴, 王邦康. Activator功能矫治对髁突、关节窝和下颌骨生长改形的影响研究:X线头影测量研究[J]. 现代口腔医学杂志, 2007, 21(2):129-131.
[29]	Nindra J, Sidhu MS, Kochhar AS, et al. Three-dimensional evaluation of condyle-glenoid Fossa complex following treatment with herbst appliance[J]. J Clin Med, 2021, 10(20):4730. doi: 10.3390/jcm10204730
[30]	LeCornu M, Cevidanes LHS, Zhu HT, et al. Three-dimensional treatment outcomes in Class Ⅱ patients treated with the Herbst appliance:A pilot study[J]. Am J Orthod Dentofacial Orthop, 2013, 144(6):818-830. doi: 10.1016/j.ajodo.2013.07.014
[31]	Rabie AB, Zhao Z, Shen G, et al. Osteogenesis in the glenoid Fossa in response to mandibular advancement[J]. Am J Orthod Dentofacial Orthop, 2001, 119(4):390-400. doi: 10.1067/mod.2001.112875
