导板在正畸治疗中的矫治效能与临床应用

doi:10.13591/j.cnki.kqyx.2026.08.009

摘要/Abstract

摘要：

导板是正畸治疗中的重要辅助装置,包括固定式Bite Turbo、活动式导板及隐形矫治Bite Ramp等类型。它们通过调节咬合力分布与下颌位置,在深覆牙合、反牙合、牙合平面不对称及锁牙合等多种错牙合畸形的治疗中发挥关键作用。本文系统论述了导板治疗的生物力学基础,涵盖咬合打开、下颌引导、垂直向控制及牙齿移动调控等方面,并结合临床研究数据,分析了导板在固定矫治与隐形矫治中的具体应用及效果。结果显示,固定式导板打开咬合的效率明显高于活动导板,而隐形矫治中的Bite Ramp则能提供更舒适、精准的咬合引导。导板的应用需要严格把握适应证,尤其对高角病例应谨慎使用。随着数字化设计与材料技术的进步,导板在正畸治疗中正朝着更个性化、精准化的方向发展。

关键词: 咬合导板, 深覆牙合, 垂直向控制, 生物力学

Abstract:

Bite plates are essential auxiliary devices in orthodontic treatment, comprising various types such as fixed bite turbos, removable bite plates, and bite ramps used in clear aligner therapy. By modulating occlusal force distribution and mandibular position, these devices play a critical role in treating diverse malocclusions, including deep bite, crossbite, canted occlusal plane, and scissors bite. This review systematically elucidates the biomechanical foundations of bite plate therapy, covering bite opening, mandibular guidance, vertical control, and the regulation of tooth movement. Furthermore, combined with clinical research data, this article analyzes the specific applications and efficacy of bite plates in both fixed appliance therapy and clear aligner therapy. The findings indicate that fixed bite turbos demonstrate significantly higher efficiency in bite opening compared to removable bite plates, while bite ramps in clear aligner therapy offer more comfortable and precise occlusal guidance. However, strict adherence to indications is required when applying bite plates, with particular caution necessary for high-angle cases. With advancements in digital design and material technology, the application of bite plates in orthodontics is evolving toward greater personalization and precision.

Key words: bite plate, deep overbite, vertical control, biomechanics

中图分类号:

R783.5

翁依雅, 袁礼婵, 张梦男, 马俊青. 导板在正畸治疗中的矫治效能与临床应用[J]. 口腔医学, 2026, 46(8): 619-623.

WENG Yiya, YUAN Lichan, ZHANG Mengnan, MA Junqing. Bite plates in orthodontics: Therapeutic efficacy and clinical applications[J]. Stomatology, 2026, 46(8): 619-623.

图/表 3

参考文献 38

[1]	Nicolae XA, Preoteasa E, Murariu Magureanu C, et al. Cross-sectional study of occlusal loading and periodontal status of teeth with deflective occlusal contacts[J]. Bioengineering, 2025, 12(7): 766. doi: 10.3390/bioengineering12070766
[2]	Moreno-Fernández A, Iranzo-Cortés JE, Paredes-Gallardo V, et al. Effectiveness of removable appliances with temperature sensors in orthodontic patients: A systematic review and meta-analysis[J]. Eur J Orthod, 2022, 44(2): 134-145. doi: 10.1093/ejo/cjab033
[3]	王玉琛, 林新平, 邹明媛, 等. 不同情况下Bite Turbos对上颌中切牙作用的三维有限元分析[J]. 口腔医学研究, 2025, 41(4): 320-326. doi: 10.13701/j.cnki.kqyxyj.2025.04.009
[4]	Lee SA, Chang CCH, Roberts WE. Severe unilateral scissors-bite with a constricted mandibular arch: Bite turbos and extra-alveolar bone screws in the infrazygomatic crests and mandibular buccal shelf[J]. Am J Orthod Dentofacial Orthop, 2018, 154(4): 554-569. doi: 10.1016/j.ajodo.2017.03.032
[5]	谢雪梅, 郑庆忠, 潘晓岗. 玻璃离子水门汀垫高术在正畸治疗中的应用[J]. 实用口腔医学杂志, 2012, 28(5): 655-657.
[6]	Martinez M, Fawaz P, El Sayegh P, et al. The microhardness and chemical composition of different ceramic self-ligating brackets: An in vitro study[J]. Dent J, 2025, 13(7): 285. doi: 10.3390/dj13070285
[7]	Feagin K, Kwon SJ, Farheen F, et al. Comparison of wear of three orthodontic bite materials and opposing enamel[J]. Int Orthod, 2021, 19(3): 494-499. doi: 10.1016/j.ortho.2021.06.002
[8]	Arslan SG, Kama JD, Baran S. Correction of a severe Class Ⅲ malocclusion[J]. Am J Orthod Dentofacial Orthop, 2004, 126(2): 237-244. doi: 10.1016/j.ajodo.2003.07.014
[9]	Le LN, Thi T, Le KPV. Non-surgery treatment with MEAW technique in skeletal Class Ⅲ malocclusion and facial asymmetry in adults: A case report[J]. Open Dent J, 2024, 18: e18742106308916.
[10]	Viet Anh N, Thi Trang N, Bich Ngoc DT. Occlusal cant correction using anterior unilateral bite turbo: A case series[J]. Int Orthod, 2025, 23(3): 100991. doi: 10.1016/j.ortho.2025.100991
[11]	Nguyen VA, Nguyen TA, Doan TBN. The effectiveness of anterior unilateral bite turbos in correcting incisal plane cant and asymmetric overbite: A prospective clinical study[J]. Sci Rep, 2025, 15(1): 15772. doi: 10.1038/s41598-025-01035-w
[12]	赵健, 罗哲, 白露. 自锁托槽结合Bite Turbo在轻中度偏牙合矫治中的临床应用研究[C]//2016中国国际正畸大会暨第十五次全国口腔正畸学术会议论文汇编. 西安,2016: 654-655.
[13]	冯敬哲. 舌侧平面导板在上颌切牙不同粘接位置打开咬合的三维有限元分析[D]. 南充: 川北医学院, 2024.
[14]	唐宇阳, 李昕彧, 徐倩倩, 等. 应用Bite Turbo矫治深覆牙合的三维有限元分析[J]. 全科口腔医学电子杂志, 2016, 3(13): 70-71.
[15]	高杨. 口腔正畸Bite Ramp平面导板三维有限元模型的建立[D]. 青岛: 青岛大学, 2015.
[16]	Pairatchawan N, Viteporn S, Thongudomporn U. Mandibular incisor root volume changes between anterior bite planes fabricated from acrylic resin and thermoplastic materials: A prospective randomized clinical trial[J]. Angle Orthod, 2022, 92(6): 755-763. doi: 10.2319/021622-141.1 pmid: 35969212
[17]	王海岚, 杨丽, 王鹏来. 自锁矫治技术结合Bite Turbo矫治青少年深覆牙合的临床研究[J]. 现代口腔医学杂志, 2020, 34(3): 140-143.
[18]	姜智妍, 刘佳, 表艳. 粘结式固定平面导板与活动平面导板的矫正治疗效果临床对比研究[J]. 延边大学医学学报, 2023, 46(3): 203-205.
[19]	赵斌. 固定矫治器结合Bite Turbos治疗深覆牙合的疗效分析[J]. 中国医疗美容, 2015, 5(6): 97-98.
[20]	Ahmad Rasol O, Hajeer MY, Alam MK, et al. Evaluation of different methods of correcting deep bite in adult and adolescent patients: A systematic review and meta-analysis[J]. Prog Orthod, 2025, 26(1): 37. doi: 10.1186/s40510-025-00586-y pmid: 41091306
[21]	Al-Zoubi EM, Al-Nimri KS. A comparative study between the effect of reverse curve of Spee archwires and anterior bite turbos in the treatment of deep overbite cases[J]. Angle Orthod, 2022, 92(1): 36-44. doi: 10.2319/020921-117.1
[22]	王静, 孙一凡, 路茜, 等. 微种植钉支抗与平面导板在下前牙过长型深覆牙合矫治中的效果评价[J]. 上海口腔医学, 2024, 33(3): 301-305.
[23]	Meade MJ, Weir T, Seehra J, et al. Clear aligner therapy practice among orthodontists in the United Kingdom and the Republic of Ireland: A cross-sectional survey of the British Orthodontic Society membership[J]. J Orthod, 2024, 51(2): 120-129. doi: 10.1177/14653125231204889
[24]	Abu-Arqub S, Ahmida A, Da Cunha Godoy L, et al. Insight into clear aligner therapy protocols and preferences among members of the American Association of Orthodontists in the United States and Canada[J]. Angle Orthod, 2023, 93(4): 417-426. doi: 10.2319/101022-694.1 pmid: 36912674
[25]	Meade MJ, Weir T. A survey of orthodontic clear aligner practices among orthodontists[J]. Am J Orthod Dentofacial Orthop, 2022, 162(6): e302-e311. doi: 10.1016/j.ajodo.2022.08.018
[26]	Goh S, Dreyer C, Weir T. The predictability of the mandibular curve of Spee leveling with the Invisalign appliance[J]. Am J Orthod Dentofac Orthop, 2022, 162(2): 193-200. doi: 10.1016/j.ajodo.2021.04.034
[27]	Goh S, Dreyer C, Weir T. The predictability of the mandibular curve of Wilson, buccolingual crown inclination, and transverse expansion expression with Invisalign treatment[J]. Am J Orthod Dentofacial Orthop, 2023, 163(1): 109-116. doi: 10.1016/j.ajodo.2021.09.020
[28]	Shahabuddin N, Kang J, Jeon HH. Predictability of the deep overbite correction using clear aligners[J]. Am J Orthod Dentofac Orthop, 2023, 163(6): 793-801. doi: 10.1016/j.ajodo.2022.07.019
[29]	Husain F, Warunek S, Gurav A, et al. Influence of Invisalign precision bite ramp utilization on deep bite correction and root length in adults[J]. Angle Orthod, 2024, 94(5): 488-495. doi: 10.2319/012724-70.1 pmid: 39230020
[30]	Henick D, Dayan W, Dunford R, et al. Effects of Invisalign(G5)with virtual bite ramps for skeletal deep overbite malocclusion correction in adults[J]. Angle Orthod, 2021, 91(2): 164-170. doi: 10.2319/072220-646.1
[31]	Greco M, Rombolà A. Precision bite ramps and aligners: An elective choice for deep bite treatment[J]. J Orthod, 2022, 49(2): 213-220. doi: 10.1177/14653125211034180
[32]	Kravitz ND, Moshiri M, Nicozisis J, et al. Mechanical considerations for deep-bite correction with aligners[J]. Semin Orthod, 2020, 26(3): 134-138. doi: 10.1053/j.sodo.2020.06.010
[33]	Blundell HL, Weir T, Byrne G. Predictability of overbite control with the Invisalign appliance comparing SmartTrack with precision bite ramps to EX30[J]. Am J Orthod Dentofacial Orthop, 2022, 162(2): e71-e81. doi: 10.1016/j.ajodo.2022.05.012
[34]	Salem AS, Albelasy NF, El-Bialy AA. Effectiveness of clear aligner versus removable inclined plane in treatment of anterior crossbite in mixed dentition: A randomized clinical trial[J]. J World Fed Orthod, 2025, 14(3): 125-130.
[35]	薛楠, 赵阳, 戚琳, 等. Bite turbo配合早期牵引治疗前牙反牙合的疗效分析[J]. 口腔医学, 2016, 36(7): 624-627.
[36]	史睿颖. 无托槽隐形矫治器设计平面导板力学效应的临床研究[D]. 西安: 中国人民解放军空军军医大学, 2024.
[37]	寇秉国. 无托槽隐形矫治器设计平面导板对上牙列牙齿移动的影响[D]. 西安: 中国人民解放军空军军医大学, 2021.
[38]	Al-Moraissi EA, Farea R, Qasem KA, et al. Effectiveness of occlusal splint therapy in the management of temporomandibular disorders: Network meta-analysis of randomized controlled trials[J]. Int J Oral Maxillofac Surg, 2020, 49(8): 1042-1056. doi: 10.1016/j.ijom.2020.01.004
