上颌前牙区多生牙的锥形束CT影像学特征研究

doi:10.13591/j.cnki.kqyx.2024.02.007

Abstract

Abstract:

Objective To analyze the radiographic characterizations of the supernumerary tooth(ST)in the anterior maxillary region using cone-beam computed tomography(CBCT), in order to help clinicians treat ST. Methods CBCT data of 805 patients were selected. The radiographic characterizations of the ST were evaluated using NNT software, including the number, morphology, location, orientation, growth condition and associated clinical complications. Gender differences of the radiographic characterizations were analysed. Results Male patients outnumbered females with a gender ratio of 2.96∶1. The majority of ST was single, conical shape, palatal, inverted orientation and impacted in both males and females, but the ratio of two ST in males was higher than that in females(P<0.001). Inverted orientation in females was higher than that in males(P<0.001). The most common ST-associated complication was bone resorption of the walls of the nasopalatine canal, and the ratio in males was higher than that in females(P=0.01). In addition, anatomical structures involved by ST and other complications also included bone resorption of nasal floor, odontogenic cyst formation, follicle gap of tooth widen, impaction, malposition, rotation and root resorption of adjacent teeth. Conclusion The majority of ST was single, conical shape, palatal, inverted orientation and impacted in both males and females, but the clinical characterizations between males and females showed significant difference. The presence of ST may produce several complications. The accurate analysis of CBCT scan assists the diagnosis and treatment of ST.

Key words: cone beam computed tomography, supernumerary tooth, complication, radiographic characterization

CLC Number:

R814.4

SUN Su, LENG Diya, WANG Jingyan, GU Peiyu, YANG Lianfeng, WU Daming, SUN Chao, ZHANG Juan. Study on the radiographic characterizations of supernumerary teeth in maxillary anterior region using cone beam computed tomography[J]. Stomatology, 2024, 44(2): 115-120.

Figures/Tables 15

Fig.1

Fig.2

Fig.3

Fig. 4

Fig.5

Fig.6

Tab.1

Tab.2

Fig.7

Tab.3

Tab.4

Tab.5

Fig.8

Fig.9

Tab.6

References 22

[1]	Demiriz L, Durmuşlar MC, Mısır AF. Prevalence and characteristics of supernumerary teeth: A survey on 7 348 people[J]. J Int Soc Prev Community Dent, 2015, 5(Suppl 1):S39-43.
[2]	Bereket C, Çakır-Özkan N, Şener İ, et al. Analyses of 1100 supernumerary teeth in a nonsyndromic Turkish population: A retrospective multicenter study[J]. Niger J Clin Pract, 2015, 18(6):731-738. doi: 10.4103/1119-3077.154213 pmid: 26289509
[3]	Chalakkal P, Krishnan R, De Souza N, et al. A rare occurrence of supplementary maxillary lateral incisors and a detailed review on supernumerary teeth[J]. J Oral Maxillofac Pathol, 2018, 22(1):149. doi: 10.4103/jomfp.JOMFP_213_15
[4]	苏莎, 战丽平, 贺彩. 基于锥形束CT的多生牙新分类方法临床意义研究[J]. 中国实用口腔科杂志, 2020, 13(9):555-558. doi: 10.19538/j.kq.2020.09.007
[5]	McBeain M, Miloro M. Characteristics of supernumerary teeth in nonsyndromic population in an Urban dental school setting[J]. J Oral Maxillofac Surg, 2018, 76(5):933-938. doi: 10.1016/j.joms.2017.10.013
[6]	Hadziabdic N, Haskic A, Mujkic A, et al. Epidemiological, clinical and radiographic features of supernumerary teeth in Nonsyndromic Bosnian and Herzegovinian population: a monocentric study[J]. Med Arch, 2022, 76(5):348-353. doi: 10.5455/medarh.2022.76.348-353 pmid: 36545455
[7]	彭博, 曾素娟, 葛林虎. 多生牙的研究进展[J]. 口腔医学研究, 2018, 34(2):209-212. doi: 10.13701/j.cnki.kqyxyj.2018.02.025
[8]	林杨, 田媛, 李文超, 等. 上颌前牙区多生牙362例临床和影像学分析[J]. 口腔颌面外科杂志, 2022, 32(3):186-191. doi: 10.3969/j.issn.1005-4979.2022.03.009
[9]	陈力, 鞠昊, 公柏娟, 等. 锥形束CT在青少年多生牙诊断中的应用[J]. 吉林大学学报(医学版), 2019, 45(2):435-438.
[10]	Shah A, Gill DS, Tredwin C, et al. Diagnosis and management of supernumerary teeth[J]. Dent Update, 2008, 35(8):510-512, 514-516, 519-520. pmid: 19055087
[11]	Ma X, Jiang Y, Ge H, et al. Epidemiological, clinical, radiographic characterization of non-syndromic supernumerary teeth in Chinese children and adolescents[J]. Oral Dis, 2021, 27(4):981-992. doi: 10.1111/odi.v27.4
[12]	Palikaraki G, Vardas E, Mitsea A. Two rare cases of non-syndromic paramolars with family occurrence and a review of literature[J]. Dent J(Basel), 2019, 7(2):38.
[13]	Zhang H, Gong X, Xu X, et al. Tooth number abnormality: from bench to bedside[J]. Int J Oral Sci, 2023, 15(1):5. doi: 10.1038/s41368-022-00208-x pmid: 36604408
[14]	Talaat DM, Hachim IY, Afifi MM, et al. Assessment of risk factors and molecular biomarkers in children with supernumerary teeth: A single-center study[J]. BMC Oral Health, 2022, 22(1):117. doi: 10.1186/s12903-022-02151-z pmid: 35397562
[15]	Jiang Y, Ma X, Wu Y, et al. Epidemiological, clinical, and 3-dimentional CBCT radiographic characterizations of supernumerary teeth in a non-syndromic adult population: A single-institutional study from 60, 104 Chinese subjects[J]. Clin Oral Investig, 2020, 24(12):4271-4281. doi: 10.1007/s00784-020-03288-3
[16]	Hajmohammadi E, Najirad S, Mikaeili H, et al. Epidemiology of supernumerary teeth in 5000 radiography films: Investigation of patients referring to the clinics of Ardabil in 2015-2020[J]. Int J Dent, 2021:6669436.
[17]	Mansour K. Ectopic supernumerary nasal tooth: a clinical case report[J]. Smile Dental Journal, 2008, 3: 28-29.
[18]	Amini F, Rakhshan V, Jamalzadeh S. Prevalence and pattern of accessory teeth(hyperdontia)in permanent dentition of Iranian orthodontic patients[J]. Iran J Public Health, 2013, 42(11):1259-1265.
[19]	Garvey MT, Barry HJ, Blake M. Supernumerary teeth-an overview of classification, diagnosis and management[J]. J Can Dent Assoc, 1999, 65(11):612-616.
[20]	Cheng FC, Chen MH, Liu BL, et al. Nonsyndromic supernumerary teeth in patients in National Taiwan University Children's hospital[J]. J Dent Sci, 2022, 17(4):1612-1618. doi: 10.1016/j.jds.2022.07.015
[21]	Park SY, Jang HJ, Hwang DS, et al. Complications associated with specific characteristics of supernumerary teeth[J]. Oral Surg Oral Med Oral Pathol Oral Radiol, 2020, 130(2):150-155. doi: 10.1016/j.oooo.2020.03.002
[22]	沙震宇, 王了. 上颌前牙区多生牙临床特征及拔除时机选择[J]. 口腔医学研究, 2020, 36(10):902-904. doi: 10.13701/j.cnki.kqyxyj.2020.10.003

数目	男性	女性	P
1枚	381(64.03)	162(77.14)	0.001
2枚	206(34.62)	47(22.38)	0.001
3枚	6(1.01)	1(0.48)	0.683
4枚	2(0.34)	0(0)	1.000

形态	男性	女性	P
锥形	718(87.67)	235(90.73)	0.184
切牙形	30(3.66)	11(4.25)	0.709
变异形	28(3.42)	5(1.93)	0.301
结节状	18(2.20)	4(1.54)	0.622
蕾状	16(1.95)	2(0.77)	0.270
前磨牙形	9(1.10)	2(0.77)	1.000

位置	男性	女性	P
腭侧	621(75.82)	203(78.38)	0.403
牙弓	139(16.97)	29(11.20)	0.300
上方	49(5.98)	22(8.49)	0.195
下方	9(1.10)	5(1.93)	0.366
唇侧	1(0.12)	0(0)	1.000

方向	男性	女性	P
倒置	403(49.21)	161(62.16)	<0.001
正向	256(31.26)	51(19.69)	<0.001
冠向腭侧水平	68(8.30)	20(7.72)	0.797
冠向腭侧远中	20(2.44)	7(2.70)	0.820
冠向腭侧近中	3(0.37)	0(0)	1.000
冠向腭侧向下	7(0.85)	0(0)	0.206
冠向唇侧近中	13(1.59)	5(1.93)	0.781
冠向唇侧远中	28(3.42)	10(3.86)	0.847
冠向唇侧水平	21(2.56)	5(1.93)	0.654

发育情况	男性	女性	P
阻生	671(81.93)	230(88.80)	0.009
根弯曲	91(11.11)	29(11.20)	1.000
发育不完全	113(13.80)	33(12.74)	0.679

Study on the radiographic characterizations of supernumerary teeth in maxillary anterior region using cone beam computed tomography

RichHTML

PDF (PC)

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 15

References 22

Related Articles 15

Recommended Articles

Metrics

Comments

并发症	男性	女性	P
鼻腭管管壁骨质吸收(人数,%)	442(74.29)	136(64.76)	0.010
鼻底骨质吸收(人数,%)	104(17.48)	41(19.52)	0.531
颌骨囊肿(人数,%)	30(5.05)	5(2.38)	0.118
牙滤泡间隙增宽考虑含牙囊肿倾向(人数,%)	19(3.19)	7(3.33)	1.000
前牙阻生(牙数)	61	14	0.279
前牙扭转(牙数)	39	10	0.405
前牙移位(牙数)	15	1	0.084
前牙根吸收(牙数)	8	0	0.120
其他颌骨异常(人数)	3	0	0.572
