新型镁合金黏膜刺激性、急性全身毒性及抗菌性能研究

doi:10.13591/j.cnki.kqyx.2023.10.003

Abstract

Abstract:

Objective To determinethe mucosal irritant, acute systemic toxicity and antibacterial propertiesof novel magnesium alloys(Mg-3Sn-0.5Mn). Methods Through the mucosal stimulation experiment of golden gopher and the acute toxicity experiment of mice, the biocompatibility of the new magnesium alloy was tested. The bacterial state on the surface of the new magnesium alloy was observed by plate counting and scanning electron microscopy after the culture of magnesium alloy and bacterial liquid(Escherichia coli and Staphylococcus aureus) for 1 d and 3 d. Results Acute systemic toxicity experiment of mice showed that during the 72 h observation period, there was no acute toxicity reaction in the experimental group and the mice in the control group. Mucosal stimulation experiment showed that after 14 d, there was no obvious abnormality between the experimental group and the control group in the cheek mucosa HE staining and gross observation of the golden gopher. Antibacterial experiment revealed that compared with 316 stainless steel in the control group, the number of bacterial colonies on the surface of the petri dish was significantly smaller, and the antibacterial effect was obvious. According to scanning electron microscope observation,the number of Staphylococcus aureus on the surface of magnesium alloy was significantly less than that of the control group, and the shape was obviously wrinkled. Conclusion The new magnesium alloy(Mg-3Sn-0.5Mn)has good biocompatibility and antibacterial properties, which can initially meet the basic requirements of medical materials.

Key words: magnesium alloy, biocompatibility, antibacterial property, mucosal stimulation experiment

CLC Number:

R783.1

CHU Maoran, LIU Juan, XIU Zhaobo, SUN Yu. Study on mucosal irritation, acute systemic toxicity and antibacterial properties of the novel magnesium alloys[J]. Stomatology, 2023, 43(10): 878-882.

Figures/Tables 7

Fig.1

Tab.1

Fig.2

Fig.3

Tab.2

Fig.4

Fig.5

References 20

[1]	Oliver AA, Sikora-Jasinska M, Demir AG, et al. Recent advances and directions in the development of bioresorbable metallic cardiovascular stents:Insights from recent human and in vivo studies[J]. Acta Biomater, 2021, 127:1-23. doi: 10.1016/j.actbio.2021.03.058
[2]	Duan HY, Cao CL, Wang XL, et al. Magnesium-alloy rods reinforced bioglass bone cement composite scaffolds with cortical bone-matching mechanical properties and excellent osteoconductivity for load-bearing bone in vivo regeneration[J]. Sci Rep, 2020, 10(1):18193. doi: 10.1038/s41598-020-75328-7
[3]	Hou RQ, Victoria-Hernandez J, Jiang PL, et al. In vitro evaluation of the ZX11 magnesium alloy as potential bone plate:Degradability and mechanical integrity[J]. Acta Biomater, 2019, 97:608-622. doi: 10.1016/j.actbio.2019.07.053
[4]	Wagner FC, Post A, Yilmaz T, et al. Biomechanical comparison of biodegradable magnesium screws and titanium screws for operative stabilization of displaced capitellar fractures[J]. J Shoulder Elb Surg, 2020, 29(9):1912-1919. doi: 10.1016/j.jse.2020.02.009
[5]	Imwinkelried T, Beck S, Schaller B. Pre-clinical testing of human size magnesium implants in miniature pigs:Implant degradation and bone fracture healing at multiple implantation sites[J]. Mater Sci Eng C, 2020, 108:110389. doi: 10.1016/j.msec.2019.110389
[6]	Ma DL, Wang J, Zheng MR, et al. Degradation behavior of ZE21C magnesium alloy suture anchors and their effect on ligament-bone junction repair[J]. Bioact Mater, 2023, 26:128-141. doi: 10.1016/j.bioactmat.2023.02.021 pmid: 36891259
[7]	国家药品监督管理局. 口腔医疗器械生物学评价第13部分:口腔黏膜刺激试验:YY/T 0127.13—2018[S]. 北京: 中国标准出版社, 2018.
[8]	国家质量监督检验检疫总局, 中国国家标准化管理委员会. 医疗器械生物学评价第11部分:全身毒性试验:GB/T 16886.11—2011[S]. 北京: 中国标准出版社, 2012.
[9]	刘西伟. Mg-3Sn-0.5Mn合金的降解行为及生物相容性[D]. 哈尔滨: 哈尔滨工程大学, 2013.
[10]	焦二龙, 孙宇, 肖睿, 等. 高熵合金AlCoCrCuFeTix小鼠急性全身毒性及兔皮下植入实验研究[J]. 哈尔滨医科大学学报, 2019, 53(6):571-575.
[11]	孙宇, 黄永江, 范洪波, 等. 齿科修复用Zr-Cu-AL-Ag合金的生物安全性评价[J]. 临床口腔医学杂志, 2014, 30(4):202-204.
[12]	Pickering G, Mazur A, Trousselard M, et al. Magnesium status and stress:The vicious circle concept revisited[J]. Nutrients, 2020, 12(12):3672. doi: 10.3390/nu12123672
[13]	Fiorentini D, Cappadone C, Farruggia G, et al. Magnesium: Biochemistry, nutrition, detection, and social impact of diseases linked to its deficiency[J]. Nutrients, 2021, 13(4):1136. doi: 10.3390/nu13041136
[14]	Xie B, Zhao MC, Xu R, et al. Biodegradation, antibacterial performance, and cytocompatibility of a novel ZK30-Cu-Mn biomedical alloy produced by selective laser melting[J]. Int J Bioprint, 2020, 7(1):300. doi: 10.18063/ijb.v7i1.300
[15]	胡欣, 魏强, 李长义, 等. 新型口腔修复用钛锆铌锡合金的生物安全性评价[J]. 口腔颌面修复学杂志, 2010, 11(1):33-36.
[16]	Wang N, Ma YT, Shi HX, et al. Mg-, Zn-, and Fe-based alloys with antibacterial properties as orthopedic implant materials[J]. Front Bioeng Biotechnol, 2022, 10:888084. doi: 10.3389/fbioe.2022.888084
[17]	Emelyanenko AM, Domantovsky AG, Kaminsky VV, et al. The mechanisms of antibacterial activity of magnesium alloys with extreme wettability[J]. Materials(Basel), 2021, 14(18):5454.
[18]	Brooks EK, Ahn R, Tobias ME, et al. Magnesium alloy AZ91 exhibits antimicrobial properties in vitro but not in vivo[J]. J Biomed Mater Res B Appl Biomater, 2018, 106(1):221-227. doi: 10.1002/jbm.b.v106.1
[19]	Li M, Zhang D, Peng F, et al. Zinc-doped ferric oxyhydroxide nano-layer enhances the bactericidal activity and osseointegration of a magnesium alloy through augmenting the formation of neutrophil extracellular traps[J]. Acta Biomater, 2022, 152:575-592. doi: 10.1016/j.actbio.2022.08.066 pmid: 36070834
[20]	Hou P, Zhao CL, Cheng PF, et al. Reduced antibacterial property of metallic magnesium in vivo[J]. Biomed Mater, 2016, 12(1):015010. doi: 10.1088/1748-605X/12/1/015010

分组	实验前	24 h	48 h	72 h
Mg-3Sn-0.5Mn	24.95±2.21	25.68±2.24	27.08±2.26	28.32±2.33
对照组	25.70±2.45	27.19±3.00	29.01±3.03	30.09±3.27

菌种	分组	菌落中位数/个		Z	P
菌种	分组	实验组	对照组	Z	P
S.aureus	1 d游离菌	601	996	-2.402	0.016
	1 d黏附菌	437	980	-2.402	0.016
	3 d游离菌	241	1 389	-2.611	0.009
	3 d黏附菌	141	508	-2.611	0.009
E.coli	1 d游离菌	119	445	-2.611	0.009
	1 d黏附菌	138	903	-2.611	0.009
	3 d游离菌	9	2 048	-2.611	0.009
	3 d黏附菌	11	1 460	-2.611	0.009
