非综合征唇腭裂患者与骨性Ⅲ类人群的上气道三维结构分析研究

doi:10.13591/j.cnki.kqyx.2023.06.009

Abstract

Abstract:

Objective To conduct a three-dimensional comparative study on upper airway symmetry between patients with non-syndromic cleft lip and palate and populations with skeletal Class Ⅲ. Methods Fifty-one cases of non-syndromic cleft lip and palate patientsand 50 cases of skeletal Class Ⅲ populationswere included. Cone-beam CT was taken, and Dolphin 3D 11.9 software was used for three-dimensional measurement and analysis. SPSS 25.0 software package was used for independent sample test to compare the volume, height and minimum area of the upper airway. Results The minimum cross-sectional area of the upper airway nasopharyngeal segment of patients with non-syndromic cleft lip and palate was larger than that of skeletal Class Ⅲ population(P<0.01). The upper airway pharyngeal segment height of patients with non-syndromic cleft lip and palate was smaller than that of skeletal Class Ⅲ population(P<0.01). There was no significant difference in the other segments of the upper airway(P>0.05). Conclusion There are differences in the three-dimensional structure of the upper airway between NSCLP patients and skeletal Ⅲ population, except for the similarity in the glossopharyngeal segment, indicating that the cause of cleft lip and palate is not only abnormal anatomical structure, but also affected by other functional factors. Therefore, respiratory problems need multi-disciplinary diagnosis and treatment.

Key words: non-syndromic cleft lip, cone-beam CT, upper airway

CLC Number:

R783.5

XIAO Yuhuan, HOU Wei, SHI Jiali, LIU Fei, WANG Zhendong, ZHOU Weina. Three-dimensional analysis of upper airway in patients with non-syndromic cleft lip and palate and skeletal Class Ⅲ[J]. Stomatology, 2023, 43(6): 529-533.

Figures/Tables 6

Fig.1

Fig.2

Tab.1

Fig.3

Fig.4

Tab.2

References 28

[1]	Louro RS, Calasans-Maia JA, Mattos CT, et al. Three-dimensional changes to the upper airway after maxillomandibular advancement with counterclockwise rotation: A systematic review and meta-analysis[J]. Int J Oral Maxillofac Surg, 2018, 47(5):622-629. doi: 10.1016/j.ijom.2017.11.003
[2]	Zreaqat M, Hassan R, Samsudin R, et al. Three-dimensional analysis of upper airways in Class Ⅱ malocclusion children with obstructive sleep apnea[J]. J World Fed Orthod, 2022, 11(5):156-163.
[3]	Wang XY, Chen H, Jia L, et al. The relationship between three-dimensional craniofacial and upper airway anatomical variables and severity of obstructive sleep apnoea in adults[J]. Eur J Orthod, 2022, 44(1):78-85. doi: 10.1093/ejo/cjab014
[4]	Faber J, Faber C, Faber AP. Obstructive sleep apnea in adults[J]. Dental Press J Orthod, 2019, 24(3):99-109. doi: S2176-94512019000300099 pmid: 31390456
[5]	宋娟. 单侧完全性唇腭裂患者鼻腔通气情况的临床研究[J]. 口腔医学研究, 2020, 36(1):24-27. doi: 10.13701/j.cnki.kqyxyj.2020.01.007
[6]	Loureiro NB, Marzano-Rodrigues MN, Trindade-Suedam IK, et al. Assessment of internal nasal dimensions of individuals with cleft lip and palate and obstructive sleep apnea syndrome by computed tomography[J]. Cleft Palate Craniofac J, 2022.doi: 10.1177/10556656221133606. doi: 10.1177/10556656221133606
[7]	Gorucu-Coskuner H, Saglam-Aydinatay B, Aksu M, et al. Comparison of positive screening for obstructive sleep apnea in patients with and without cleft lip and palate[J]. Cleft Palate Craniofac. 2020, 57(3):364-370. doi: 10.1177/1055665619875321
[8]	Fu Z, Lin Y, Ma L, Li W. Effects of maxillary protraction the rapy on the pharyngeal airway in patients with repaired unilateral cleft lip and palate: A 3-dimensional computed tomographic study. Am J Orthod Dentofacial Orthop. 2016, 149(5):673-682. doi: 10.1016/j.ajodo.2015.10.024
[9]	Ferlias N, Gjørup H, Doherty MA, et al. Obstructive sleep apnoea in pycnodysostosis: A three-dimensional upper airway analysis[J]. Orthod Craniofac Res, 2022, 25(4):494-501. doi: 10.1111/ocr.v25.4
[10]	Abé-Nickler MD, Pörtner S, Sieg P, et al. No correlation between two-dimensional measurements and three-dimensional configuration of the pharyngeal upper airway space in cone-beam computed tomography[J]. J Cranio Maxillofac Surg, 2017, 45(3):371-376. doi: 10.1016/j.jcms.2017.01.004
[11]	Hui C, Ghizlane A, Jan de L. The Effects of Noncontinuous Positive Airway Pressure Therapies on the Aerodynamic Characteristics of the Upper Airway of Obstructive Sleep Apnea Patients: A Systematic Review[J]. J Oral Maxillofac Surg,. 2018, 76(7):1559.e1-1559.e11.
[12]	Mouhanna-Fattal C, Papadopoulos M, Bouserhal J, et al. Evaluation of upper airway volume and craniofacial volumetric structures in obstructive sleep apnoea adults: A descriptive CBCT study[J]. Int Orthod, 2019, 17(4):678-686. doi: 10.1016/j.ortho.2019.08.005
[13]	苏咏宽, 韩霖霏, 李媛, 等. 非综合征唇腭裂患者与骨性Ⅰ类人群的上气道三维分析研究[J]. 口腔医学, 2019, 39(8):697-700.
[14]	侯伟, 李琥, 耿忠楷, 等. 双𬌗垫矫治器对青少年骨性Ⅱ类下颌后缩患者上气道形态的影响[J]. 南京医科大学学报(自然科学版), 2017, 37(12):1674-1677.
[15]	史建陆, 董丽玲, 李芸, 等. 安氏Ⅱ类下颌后缩儿童应用Twin-block矫治器功能矫治前后上气道变化的锥形束CT研究[J]. 实用口腔医学杂志, 2015, 31(4):531-535.
[16]	Severt TR, Proffit WR. The prevalence of facial asymmetry in the dentofacial deformities population at the University of North Carolina[J]. Int J Adult Orthodon Orthognath Surg, 1997, 12(3):171-176. pmid: 9511487
[17]	Arens R, Marcus CL. Pathophysiology of upper airway obstruction: A developmental perspective[J]. Sleep, 2004, 27(5):997-1019. pmid: 15453561
[18]	Castro-Silva L, Monnazzi MS, Spin-Neto R, et al. Cone-beam evaluation of pharyngeal airway space in Class Ⅰ, Ⅱ, and Ⅲ patients[J]. Oral Surg Oral Med Oral Pathol Oral Radiol, 2015, 120(6):679-683. doi: 10.1016/j.oooo.2015.07.006
[19]	Iwasaki T, Hayasaki H, Takemoto Y, et al. Oropharyngeal airway in children with Class Ⅲ malocclusion evaluated by cone-beam computed tomography[J]. Am J Orthod Dentofacial Orthop, 2009, 136(3):318.e1-318.e9;

[20]	Lee UL, Oh H, Min SK, et al. The structural changes of upper airway and newly developed sleep breathing disorders after surgical treatment in Class Ⅲ malocclusion subjects[J]. Medicine, 2017, 96(22):e6873. doi: 10.1097/MD.0000000000006873
[21]	Ming Y, Hu Y, Li YY, et al. Effects of maxillary protraction appliances on airway dimensions in growing Class Ⅲ maxillary retrognathic patients: A systematic review and meta-analysis[J]. Int J Pediatr Otorhinolaryngol, 2018, 105:138-145. doi: 10.1016/j.ijporl.2017.12.013
[22]	ErtaʂÜ, Ataol M. Evaluation of nasal airway volume of operated unilateral cleft lip and palate patients compared with skeletal Class Ⅲ individuals[J]. Cleft Palate Craniofac, 2019, 56(1):15-20. doi: 10.1177/1055665618774024
[23]	邱赛男, 郝洁, 于汉英, 等. 唇腭裂患者与安氏Ⅰ类错𬌗患者上颌骨发育比较[J]. 临床口腔医学杂志, 2016, 32(3):134-138.
[24]	Chen H, Aarab G, et al. Three-dimensional imaging of the upper airway anatomy in obstructive sleep apnea: A systematic review[J]. Sleep Med, 2016, 21: 19-27. doi: 10.1016/j.sleep.2016.01.022 pmid: 27448467
[25]	Celikoglu M, Buyuk SK, Sekerci AE, et al. Three-dimensional evaluation of the pharyngeal airway volumes in patients affected by unilateral cleft lip and palate[J]. Am J Orthod Dentofac Orthop, 2014, 145(6):780-786. doi: 10.1016/j.ajodo.2014.02.008
[26]	Karia H, Shrivastav S, Karia AK. Three-dimensional evaluation of the airway spaces in patients with and without cleft lip and palate: A digital volume tomographic study[J]. Am J Orthod Dentofac Orthop, 2017, 152(3):371-381. doi: 10.1016/j.ajodo.2016.12.026
[27]	Liao YF, Yun C, Huang CS, et al. Longitudinal follow-up of obstructive sleep apnea following Furlow palatoplasty in children with cleft palate: A preliminary report[J]. Cleft Palate Craniofac J, 2003, 40(3):269-273. doi: 10.1597/1545-1569(2003)040<0269:LFOOSA>2.0.CO;2
[28]	El H, Palomo JM. Measuring the airway in 3 dimensions: A reliability and accuracy study[J]. Am J Orthod Dentofac Orthop, 2010, 137(4):S50.e1-S50.e9. doi: 10.1016/j.ajodo.2010.01.014

测量项目	定义
V_总/mm³	上气道总体积,自上气道穹隆顶至会厌顶平面,即V鼻咽+腭咽+舌咽
V_鼻咽/mm³	鼻咽体积,自上气道穹隆顶至前鼻棘平面
V_腭咽/mm³	腭咽体积,自前鼻棘平面至软腭游离缘平面
V_舌咽/mm³	舌咽体积,自软腭游离缘平面至会厌顶平面
S_鼻咽/mm²	鼻咽段最小横截面积(根据软件测定)
S_腭咽/mm²	腭咽段最小横截面积(根据软件测定)
S_舌咽/mm²	舌咽段最小横截面积(根据软件测定)
H_总/mm	上气道总高度,自上气道穹隆顶至会厌顶平面,即H鼻咽+腭咽+舌咽
H_鼻咽/mm	鼻咽高度,自上气道穹隆顶至前鼻棘平面
H_腭咽/mm	腭咽高度,自前鼻棘平面至软腭游离缘平面
H_舌咽/mm	舌咽高度,自软腭游离缘平面至会厌顶平面

测量项目	试验组(n=51)	对照组(n=50)	P
V_总/mm³	17 024.9±5 532.2	16 152.5±5 165.1	0.415
V_鼻咽/mm³	6 456.5±2 528.9	5 688.2±2 118.3	0.101
V_腭咽/mm³	5 778.5±2 475.9	6 137.5±2 528.6	0.473
V_舌咽/mm³	4 789.9±2 064.4	4 326.8±2 085.1	0.265
S_鼻咽/mm²	160.8±80.6	98.0±36.4	0.000^**
S_腭咽/mm²	70.1±44.9	66.6±25.6	0.630
S_舌咽/mm²	81.1±41.2	84.0±28.1	0.677
H_总/mm	56.15±8.38	60.84±8.37	0.006^**
H_鼻咽/mm	15.50±3.64	15.47±3.24	0.965
H_腭咽/mm	20.28±5.56	25.95±4.55	0.000^**
H_舌咽/mm	20.37±5.28	19.42±4.31	0.323
