不同声能冲洗激活器辅助清理弯曲根管玷污层的扫描电镜研究

doi:10.13591/j.cnki.kqyx.2023.07.005

Abstract

Abstract:

Objective To evaluate the efficacy of different acoustic irrigation activators assisted with smear layer removal in curved root canals. Methods Sixty-six extracted human mature molars with L-shaped root canals in Vertucci type Ⅰ configuration system were chosen. The mean angles of curvature, radius and curve length after ProTaper Next instrumentation were 39.9°±8.4°, (2.5±1.1) mm and (4.7±0.5) mm respectively. They were randomly assigned to one control group(n=6) and five experimental groups(n=12) for final irrigation as follows: no additional irrigation, Manual dynamic irrigation (MDI), Ultrasonic activation with a K-type file size 15/.02 (U-K) and Irrisafe20/.00 (U-IRR), Sonic activation with EndoActivator25/.04 (EA) and EDDY20/.04 (ED). The apical 6 mm of root canals were cleaved in half as the curved outer and inner sidewalls, and observed with scanning electron microscopy (SEM) in three 2 mm segments each as coronal-middle-apical thirds. The smear layer was evaluated using a five-score scale and a statistical analysis was conducted. Results All tested groups had a cleaner canal wall than the control group at any level of the root canal curved portion (P<0.05). At the coronal-third of outer canal wall, both U-IRR and ED scored smaller than others, and had a significant difference with MDI and EA (P<0.05); at the inner wall, U-K scored the highest and was inferior to both U-IRR and the two sonic activators (P<0.05). At the middle-third part and also the most curved canal area, ED was superior to U-K at two sidewalls and to EA at the inner wall (P<0.05). At the apical-third of outer canal wall, U-IRR and ED were superior to MDI (P<0.05); at the inner wall, there was no statistical difference among them. The cleanliness at apical outer wall was unsatisfactory, which was inferior to coronal inner wall in MDI/EA/ED and to apical inner wall in U-K/U-IRR (P<0.05). Conclusion ED and U-IRR assisted with smear layer removal have better performance in curved root canal, and the cleanliness at apical outer canal wall needs to be enhanced.

Key words: irrigant activation, smear layer, canal curvature

CLC Number:

R781.05

WANG Yanru, LU Yaqian, ZHAO Qitong, LI Jin. Efficacy of different acoustic irrigation activators assisted with smear layer removal in curved root canals: A SEM evaluation[J]. Stomatology, 2023, 43(7): 608-613.

Figures/Tables 8

Fig.1

Fig.2

Fig.3

Tab.1

Fig.4

Fig.5

Fig.6

Tab.2

References 37

[1]	Violich DR, Chandler NP. The smear layer in endodontics-a review[J]. Int Endod J, 2010, 43(1):2-15. doi: 10.1111/j.1365-2591.2009.01627.x pmid: 20002799
[2]	Wang ZJ, Shen Y, Haapasalo M. Effect of smear layer against disinfection protocols on Enterococcus faecalis-infected dentin[J]. J Endod, 2013, 39(11):1395-1400. doi: 10.1016/j.joen.2013.05.007
[3]	Mirseifinejad R, Tabrizizade M, Davari A, et al. Efficacy of different root canal irrigants on smear layer removal after post space preparation: A scanning electron microscopy evaluation[J]. Iran Endod J, 2017, 12(2):185-190.
[4]	Haapasalo M, Shen Y, Wang Z, et al. Irrigation in endodontics[J]. Br Dent J, 2014, 216(6):299-303. doi: 10.1038/sj.bdj.2014.204
[5]	Blank-Gonçalves LM, Nabeshima CK, Martins GHR, et al. Qualitative analysis of the removal of the smear layer in the apical third of curved roots: Conventional irrigation versus activation systems[J]. J Endod, 2011, 37(9):1268-1271. doi: 10.1016/j.joen.2011.06.009 pmid: 21846545
[6]	Munoz HR, Camacho-Cuadra K. In vivo efficacy of three different endodontic irrigation systems for irrigant delivery to working length of mesial canals of mandibular molars[J]. J Endod, 2012, 38(4):445-448. doi: 10.1016/j.joen.2011.12.007
[7]	Galler KM, Grubmüller V, Schlichting R, et al. Penetration depth of irrigants into root dentine after sonic, ultrasonic and photoacoustic activation[J]. Int Endod J, 2019, 52(8):1210-1217. doi: 10.1111/iej.13108 pmid: 30828819
[8]	Retsas A, Koursoumis A, Tzimpoulas N, et al. Uncontrolled removal of dentin during in vitro ultrasonic irrigant activation inCurvedRoot canals[J]. J Endod, 2016, 42(10):1545-1549. doi: 10.1016/j.joen.2016.07.006
[9]	Al-Jadaa A, Paqué F, Attin T, et al. Acoustic hypochlorite activation in simulated curved canals[J]. J Endod, 2009, 35(10):1408-1411. doi: 10.1016/j.joen.2009.07.007 pmid: 19801241
[10]	Boutsioukis C, Arias-Moliz MT. Present status and future directions-irrigants and irrigation methods[J]. Int Endod J, 2022, 55(Suppl 3):588-612. doi: 10.1111/iej.v55.s3
[11]	Chaniotis A, Ordinola-Zapata R. Present status and future directions: Management of curved and calcified root canals[J]. Int Endod J, 2022, 55(Suppl 3):656-684. doi: 10.1111/iej.v55.s3
[12]	Pruett JP, Clement DJ, Carnes DL. Cyclic fatigue testing of nickel-titanium endodontic instruments[J]. J Endod, 1997, 23(2):77-85. doi: 10.1016/S0099-2399(97)80250-6
[13]	Pallavi RY, Kavita S, Subbarao CV. Cyclic fatigue testing of three different rotary nickel titanium endodontic instruments in simulated curved canals-an in vitro sem analysis[J]. J Clin Diagn Res, 2014, 8(2):211-213.
[14]	ElAyouti A, Dima E, Judenhofer MS, et al. Increased apical enlargement contributes to excessive dentin removal in curved root canals: A stepwise microcomputed tomography study[J]. J Endod, 2011, 37(11):1580-1584. doi: 10.1016/j.joen.2011.08.019 pmid: 22000468
[15]	黄正秋, 于明州, 周娜, 等. 真实牙根管冲洗过程的数值模拟[J]. 力学与实践, 2021, 43(3):386-392.
[16]	Zhou N, Huang ZQ, Yu MZ, et al. Influence of needle working length and root canal curvature on irrigation: A computational fluid dynamics analysis based on a real tooth[J]. BMC Oral Health, 2022, 22(1):179. doi: 10.1186/s12903-022-02205-2 pmid: 35568838
[17]	Caron G, Nham K, Bronnec F, et al. Effectiveness of different final irrigant activation protocols on smear layer removal in curved canals[J]. J Endod, 2010, 36(8):1361-1366. doi: 10.1016/j.joen.2010.03.037 pmid: 20647097
[18]	Tay FR, Gu LS, Schoeffel GJ, et al. Effect of vapor lock on root canal debridement by using a side-vented needle for positive-pressure irrigant delivery[J]. J Endod, 2010, 36(4):745-750. doi: 10.1016/j.joen.2009.11.022 pmid: 20307757
[19]	张含, 王素苹, 任颖超, 等. 不同辅助根管冲洗技术对根管壁清洁效果的实验研究[J]. 口腔医学研究, 2021, 37(9):805-809. doi: 10.13701/j.cnki.kqyxyj.2021.09.008
[20]	Yang Q, Liu MW, Zhu LX, et al. Micro-CT study on the removal of accumulated hard-tissue debris from the root canal system of mandibular molars when using a novel laser-activated irrigation approach[J]. Int Endod J, 2020, 53(4):529-538. doi: 10.1111/iej.13250 pmid: 31710382
[21]	Hu SS, Duan LL, Wan QB, et al. Evaluation of needle movement effect on root canal irrigation using a computational fluid dynamics model[J]. Biomed Eng Online, 2019, 18(1):52. doi: 10.1186/s12938-019-0679-5 pmid: 31060550
[22]	Pereira TC, Boutsioukis C, Dijkstra RB, et al. Biofilm removal from a simulated isthmus and lateral canal during syringe irrigation at various flow rates: A combined experimental and Computational Fluid Dynamics approach[J]. Int Endod J, 2021, 54(3):427-438. doi: 10.1111/iej.v54.3
[23]	Robinson JP, Macedo RG, Verhaagen B, et al. Cleaning lateral morphological features of the root canal: The role of streaming and cavitation[J]. Int Endod J, 2018, 51(Suppl 1):e55-e64. doi: 10.1111/iej.2018.51.issue-S1
[24]	Estrela C, Bueno MR, Sousa-Neto MD, et al. Method for determination of root curvature radius using cone-beam computed tomography images[J]. Braz Dent J, 2008, 19(2):114-118. doi: S0103-64402008000200005 pmid: 18568224
[25]	Gu YC, Lu Q, Wang P, et al. Root canal morphology of permanent three-rooted mandibular first molars: Part Ⅱ: Measurement of root canal curvatures[J]. J Endod, 2010, 36(8):1341-1346. doi: 10.1016/j.joen.2010.04.025
[26]	Rius L, Arias A, Aranguren JM, et al. Analysis of the smear layer generated by different activation systems: An in vitro study[J]. Clin Oral Invest, 2021, 25(1):211-218. doi: 10.1007/s00784-020-03355-9
[27]	Turkaydin D, Basturk FB, Goker S, et al. Efficacy of Endoactivator, Canal Brush and passive ultrasonic irrigation in the removal of calcium hydroxide paste with iodoform and p-chlorophenol from root canals[J]. Niger J Clin Pract, 2020, 23(9):1237-1242. doi: 10.4103/njcp.njcp_710_19 pmid: 32913162
[28]	Wang H, Yang XQ, Zou L, et al. Shaping outcome of ProTaper NEXT for root canal preparation in mandibular incisors: A micro-CT study[J]. BMC Oral Health, 2022, 22(1):302. doi: 10.1186/s12903-022-02335-7 pmid: 35869473
[29]	封菲, 曹立群, 张旗. 新型镍钛器械弯曲根管成形能力的研究进展[J]. 口腔医学, 2020, 40(10):940-946.
[30]	江波, 黄静. 不同镍钛器械在弯曲根管预备中的比较[J]. 口腔医学研究, 2019, 35(4):331-334. doi: 10.13701/j.cnki.kqyxyj.2019.04.007
[31]	Bryce G, MacBeth N, Gulabivala K, et al. The efficacy of supplementary sonic irrigation using the EndoActivator system determined by removal of a collagen film from anex vivo model[J]. Int Endod J, 2018, 51(4):489-497. doi: 10.1111/iej.12870 pmid: 29106737
[32]	Dashtimoghadam E, Johnson A, Fahimipour F, et al. Vibrational and sonochemical characterization of ultrasonic endodontic activating devices for translation to clinical efficacy[J]. Mater Sci Eng C Mater Biol Appl, 2020, 109:110646. doi: 10.1016/j.msec.2020.110646
[33]	伊丽娜, 侯惠敏, 韩宇. 两种根管镍钛锉对L形和S形根管成形能力的研究[J]. 北京口腔医学, 2021, 29(1):42-46.
[34]	Boutsioukis C, Verhaagen B, Walmsley AD, et al. Measurement and visualization of file-to-wall contact during ultrasonically activated irrigation in simulated canals[J]. Int Endod J, 2013, 46(11):1046-1055. doi: 10.1111/iej.12097 pmid: 23521118
[35]	Jiang LM, Verhaagen B, Versluis M, et al. Evaluation of a sonic device designed to activate irrigant in the root canal[J]. J Endod, 2010, 36(1):143-146. doi: 10.1016/j.joen.2009.06.009
[36]	Ahmad M, Pitt Ford TR, Crum LA, et al. Ultrasonic debridement of root canals: Acoustic cavitation and its relevance[J]. J Endod, 1988, 14(10):486-493. doi: 10.1016/S0099-2399(88)80105-5
[37]	Swimberghe RCD, Buyse R, Meire MA, et al. Efficacy of different irrigation technique in simulated curved root canals[J]. Lasers Med Sci, 2021, 36(6):1317-1322. doi: 10.1007/s10103-021-03263-8

组别	弯曲角度α/(°)	弯曲半径r/mm	弯曲长度L/mm
MDI	39.5±9.1	2.6±0.9	4.7±0.5
U-K	39.8±8.9	2.3±1.2	4.5±0.4
U-IRR	39.6±8.9	2.3±1.2	4.8±0.4
EA	40.3±7.9	2.5±0.9	4.7±0.5
ED	40.4±8.3	2.8±1.2	4.8±0.7
合计	39.9±8.4	2.5±1.1	4.7±0.5

组别	上段2 mm		中段2 mm		下段2 mm
组别	外侧壁	内侧壁	外侧壁	内侧壁	外侧壁	内侧壁
MDI	4.0(3.1,4.4)^a	3.5(2.5,4.0)^ab*	4.0(3.5,4.4)^ab	2.8(2.0,4.0)^ab*	4.3(4.0,4.9)^a	2.8(1.6,4.9)
U-K	4.0(1.8,4.5)^abc	4.0(3.5,4.5)^a#	4.0(3.5,4.4)^a#	4.0(3.1,4.5)^a	4.0(3.1,4.4)^ab#	3.0(1.1,3.9)
U-IRR	3.0(2.1,3.9)^bc	3.0(2.5,3.5)^b	3.0(2.0,4.0)^ab#	2.5(1.5,4.4)^ab	3.8(2.8,4.0)^b#	2.0(1.5,3.0)
EA	4.0(3.5,4.0)^ab	2.8(2.1,3.9)^b	4.0(3.1,4.4)^ab&	3.8(3.0,4.0)^a	4.0(3.1,4.5)^ab&	3.5(2.0,4.5)
ED	2.0(1.5,3.3)^c*	3.0(2.1,3.2)^b*	3.0(2.1,3.5)^b*	2.5(2.0,3.0)^b*	4.0(3.1,4.0)^b	3.0(2.1,3.5)^*
