骨性Ⅲ类高角伴偏颌对上气道形态及舌骨位置的影响

doi:10.13591/j.cnki.kqyx.2024.09.004

Abstract

Abstract:

Objective To apply cone beam CT measurements(CBCT)to analyze the effect of skeletal Class Ⅲ high angle with deviation on upper airway morphology and hyoid position. Methods A total of 120 patients with skeletal Class Ⅲ high angle malocclusion who visited our hospital from September 2019 to December 2022 were selected. CBCT was taken in all subjects. According to the degree of mandibular deviation (MD) of the point under the chin from the median sagittal plane, the 120 patients were divided into three groups: non-migratory, mildly migratory, and severely migratory groups, and the volume of the upper airway as well as the position of the hyoid bone of three groups were measured and analyzed respectively. Results There was no significant difference in the volume and minimum cross-sectional area of the nasopharyngeal segment, palatopharyngeal segment, and minimum cross-sectional area of the laryngopharyngeal segment. No siginificant difference was found between the position of the hyoid bone(HB) on the Y-axis (Y-HB) and the position of the hyoid bone on the Z-axis(Z-HB) among the three groups(P>0.05). Compared with the other two groups, the volume and total volume of the nasopharyngeal segment, the laryngopharyngeal segment, and minimum cross-sectional area of the laryngopharyngeal segment in the group of severe deviation were significantly reduced(P<0.05) and X-HB was significantly larger(P<0.05). Conclusion In patients with skeletal Class Ⅲ hyperkeratosis with severe deviation, the total volume of the glossopharyngeal segment, laryngopharyngeal segment, and upper airway, as well as the minimum cross-sectional area of the glossopharyngeal segment were smaller than those of the othertwo groups. In patients with severe deviation, the position of the hyoid bone(HB) in the X-axis(X-HB) was larger than that of the non-migratory group, indicating that migratory jaws mainly affect the morphology of the lingual-pharyngeal segment as well as the laryngopharyngeal segment of the upper airway;the effect of migratory jaws on the hyoid bone is reflected in the X-HB, indicating that migratory jaws can lead to the deviation of the hyoid bone from the median sagittal plane.

Key words: skeletal Class Ⅲ, high angle, deviated jaw, upper airway, hyoid bone

CLC Number:

R783.5

WANG Gang, TANG Jinqiao, FENG Yu, LI Mengru, WANG Xiaoqin. The effect ofskeletal Class Ⅲ high angle with deviation on upper airway morphology and hyoid position[J]. Stomatology, 2024, 44(9): 658-662.

Figures/Tables 8

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Tab.1

Tab.2

Tab.3

References 37

[1]	Naros A, Wolf JA, Krimmel M, et al. Three-dimensional quantification of facial asymmetry in children with positional cranial deformity[J]. Plast Reconstr Surg, 2021, 148(6):1321-1331. doi: 10.1097/PRS.0000000000008564 pmid: 34847120
[2]	Cheong YW, Lo LJ. Facial asymmetry: Etiology, evaluation, and management[J]. Chang Gung Med J, 2011, 34(4):341-351.
[3]	Severt TR, Proffit WR. The prevalence of facial asymmetry in the dentofacial deformities population at the University of North Carolina[J]. Int J Adult Orthod Orthognath Surg, 1997, 12(3):171-176.
[4]	徐玉婷, 张晓蓉. 下颌偏斜畸形的诊治进展[J]. 医学综述, 2019, 25(6):1192-1196.
[5]	Ha SW, Kim SJ, Choi JY, et al. Characterization of facial asymmetry phenotypes in adult patients with skeletal Class Ⅲ malocclusion using three-dimensional computed tomography and cluster analysis[J]. Korean J Orthod, 2022, 52(2):85-101.
[6]	Rodríguez-Olivos LHG, Chacón-Uscamaita PR, Quinto-Argote AG, et al. Deleterious oral habits related to vertical, transverse and sagittal dental malocclusion in pediatric patients[J]. BMC Oral Health, 2022, 22(1):88. doi: 10.1186/s12903-022-02122-4 pmid: 35321719
[7]	Fernandez CCA, Pereira CVCA, Luiz RR, et al. Dental anomalies in different growth and skeletal malocclusion patterns[J]. Angle Orthod, 2018, 88(2):195-201. doi: 10.2319/071917-482.1 pmid: 29215300
[8]	Anchlia S, Vyas SM, Dayatar RG, et al. Guidelines for single-stage correction of TMJ ankylosis, facial asymmetry and OSA in adults[J]. J Maxillofac Oral Surg, 2019, 18(3):419-427.
[9]	Shokri A, Mollabashi V, Zahedi F, et al. Position of the hyoid bone and its correlation with airway dimensions in different classes of skeletal malocclusion using cone-beam computed tomography[J]. Imaging Sci Dent, 2020, 50(2):105-115. doi: 10.5624/isd.2020.50.2.105 pmid: 32601585
[10]	Cheng JH, Hsiao SY, Chen CM, et al. Relationship between hyoid bone and pharyngeal airway in different skeletal patterns[J]. J Dent Sci, 2020, 15(3):286-293.
[11]	Kim MA, Kim BR, Choi JY, et al. Three-dimensional changes of the hyoid bone and airway volumes related to its relationship with horizontal anatomic planes after bimaxillary surgery in skeletal Class Ⅲ patients[J]. Angle Orthod, 2013, 83(4):623-629.
[12]	Rückschloß T, Ristow O, Berger M, et al. Relations between mandible-only advancement surgery, the extent of the posterior airway space, and the position of the hyoid bone in Class Ⅱ patients: A three-dimensional analysis[J]. Br J Oral Maxillofac Surg, 2019, 57(10):1032-1038. doi: S0266-4356(19)30349-3 pmid: 31563482
[13]	Kikuchi Yu. Three-dimensional relationship between pharyngeal airway and maxillo-facial morphology[J]. Bull Tokyo Dent Coll, 2008, 49(2):65-75. pmid: 18776718
[14]	Zheng DH, Wang XX, Ma D, et al. Upper airway asymmetry in skeletal Class Ⅲ malocclusions with mandibular deviation[J]. Sci Rep, 2017, 7(1):12185. doi: 10.1038/s41598-017-12076-1 pmid: 28939844
[15]	Matsushita K, Inoue N, Yamaguchi HO, et al. Post-operative stability after bimaxillary surgery in patients with facial asymmetry: Comparison of differences among different original skeletal Class patterns[J]. J Maxillofac Oral Surg, 2015, 14(3):789-798.
[16]	Chen YF, Liao YF, Chen YN, et al. Treatment outcome of bimaxillary surgery for asymmetric skeletal Class Ⅱ deformity[J]. Clin Oral Investig, 2019, 23(2):623-632.
[17]	Liao YF, Chen YF, Yao CF, et al. Long-term outcomes of bimaxillarysurgery for treatment of asymmetric skeletal Class Ⅲ deformity using surgery-first approach[J]. Clin Oral Investig, 2019, 23(4):1685-1693.
[18]	Zheng YC, Aljawad H, Kim MS, et al. Three-dimensional evaluation of the association between tongue position and upper airway morphology in adults: A cross-sectional study[J]. Korean J Orthod, 2023, 53(5):317-327. doi: 10.4041/kjod23.019 pmid: 37746777
[19]	Mohamed AS, Habumugisha J, Cheng B, et al. Three-dimensional evaluation of hyoid bone position in nasal and mouth breathing subjects with skeletal Class Ⅰ, and Class Ⅱ[J]. BMC Oral Health, 2022, 22(1):228. doi: 10.1186/s12903-022-02257-4 pmid: 35681197
[20]	Park JH, Kim HS, Choi SH, et al. Changes in position of the hyoid bone and volume of the pharyngeal airway after mandibular setback: Three-dimensional analysis[J]. Br J Oral Maxillofac Surg, 2019, 57(1):29-35. doi: S0266-4356(18)30674-0 pmid: 30598316
[21]	沈刚. 含颌位因素错牙合畸形与颌位重建基本原理[J]. 上海口腔医学, 2022, 31(6):561-568.
[22]	Wu ZQ, Gao XL, Long H, et al. Quantitative analysis of facial symmetry by using three-dimensional technology[J]. BMC Oral Health, 2022, 22(1):277. doi: 10.1186/s12903-022-02315-x pmid: 35799192
[23]	Ishizaki K, Suzuki K, Mito T, et al. Morphologic, functional, and occlusal characterization of mandibular lateral displacement malocclusion[J]. Am J Orthod Dentofacial Orthop, 2010, 137(4):454.e1-454.e9;discussion454-455.
[24]	Chen YJ, Yao CC, Chang ZC, et al. Characterization of facial asymmetry in skeletal Class Ⅲ malocclusion and its implications for treatment[J]. Int J Oral Maxillofac Surg, 2019, 48(12):1533-1541.
[25]	Habumugisha J, Ma SY, Mohamed AS, et al. Three-dimensional evaluation of pharyngeal airway and maxillary arch in mouth and nasal breathing children with skeletal Class Ⅰ and Ⅱ[J]. BMC Oral Health, 2022, 22(1):320. doi: 10.1186/s12903-022-02355-3 pmid: 35915494
[26]	Al Ali A, Richmond S, Popat H, et al. The influence of snoring, mouth breathing and apnoea on facial morphology in late childhood: A three-dimensional study[J]. BMJ Open, 2015, 5(9):e009027.
[27]	Kim EJ, Choi JH, Kim KW, et al. The impacts of open-mouth breathing on upper airway space in obstructive sleep apnea: 3-D MDCT analysis[J]. Eur Arch Otorhinolaryngol, 2011, 268(4):533-539. doi: 10.1007/s00405-010-1397-6 pmid: 20957487
[28]	杜颖, 王小琴, 任娟. 骨性Ⅲ类偏颌患者髁突与?氁平面特征的CBCT研究[J]. 口腔医学, 2023, 43(3): 228-232.
[29]	刘玮玮, 马俊青. 安氏Ⅰ类拔牙正畸治疗牙槽嵴高度变化的CBCT研究[J]. 口腔医学, 2022, 42(11): 1011-1014.
[30]	苏咏宽, 潘永初, 李媛, 等. 非综合征唇腭裂患者与骨性Ⅰ类人群的上气道对称性分析研究[J]. 口腔医学, 2022, 42(7): 617-621.
[31]	Chaturvedi S, Chaturvedi Y, Chowdhary S, et al. A three-dimensional analysis of nasopharyngeal airway characteristics in subjects with cleidocranial dysplasia: A CBCT study[J]. Int J Clin Pediatr Dent, 2022, 15(5):520-524.
[32]	Wen X, Wang XY, Qin SQ, et al. Three-dimensional analysis of upper airway morphology in skeletal Class Ⅲ patients with and without mandibular asymmetry[J]. Angle Orthod, 2017, 87(4):526-533. doi: 10.2319/120116-866.1 pmid: 28418700
[33]	Maniskas S, Parsaei Y, Bruckman KC, et al. Concurrent high condylectomy and orthognathic surgery to address mandibular and facial asymmetry[J]. J CraniofacSurg, 2019, 30(8):2601-2603.
[34]	Raberin M. Orthognathic surgery and facial asymmetry: Successes and disappointments[J]. Orthod Fr, 2003, 74(1):59-69. pmid: 15301377
[35]	Giap HV, Shin JW, Chae HS, et al. Pharyngeal airway morphology in skeletal Class Ⅲ with mandibular asymmetry is improved after bimaxillaryorthognathic surgery[J]. J Oral Maxillofac Surg, 2021, 79(5):1107-1121.
[36]	Irani SK, Oliver DR, Movahed R, et al. Pharyngeal airway evaluation after isolated mandibular setback surgery using cone-beam computed tomography[J]. Am J Orthod Dentofacial Orthop, 2018, 153(1):46-53.
[37]	Tan SK, Leung WK, Tang ATH, et al. Effects of mandibular setback with or without maxillary advancement osteotomies on pharyngeal airways: An overview of systematic reviews[J]. PLoS One, 2017, 12(10):e0185951.

组别	例数	鼻咽段	腭咽段	舌咽段	喉咽段	总体积
非偏颌组	40	5 984.82±1 628.83	9 874.53±3 056.34	6 048.72±1 338.62	2 989.25±668.20	24 897.33±3 220.92
轻度偏颌组	40	6 045.21±1 583.37	9 657.63±2 878.59	5 894.40±1 384.36	2 755.56±583.63	24 352.80±3 689.41
重度偏颌组	40	6 036.74±1 468.49	9 735.58±2 755.43	5 018.34±1 405.86	2 587.59±616.13	22 378.25±3 235.59
F		0.018	0.057	6.519	4.018	5.071
P		0.985	0.944	0.002	0.021	0.011

组别	例数	X-HB	Y-HB	Z-HB
非偏颌组	40	1.48±1.03	51.66±5.04	101.63±7.46
轻度偏颌组	40	1.62±0.94	53.67±4.99	100.11±8.24
重度偏颌组	40	2.81±1.12	52.49±5.37	99.68±9.21
F		20.225	1.536	0.603
P		<0.001	0.220	0.549

组别	例数	鼻咽	腭咽	舌咽	喉咽
非偏颌组	40	258.37±76.49	304.71±59.62	228.51±52.12	174.29±48.95
中度偏颌组	40	245.92±68.18	311.52±64.25	219.45±57.62	189.68±58.25
重度偏颌组	40	265.62±61.35	298.84±68.59	181.32±50.29	168.35±47.15
F		0.400	0.532	3.960	0.144
P		0.675	0.594	0.028	0.866
